NSN 4310-01-568-1157 U4-20, U420, 01-568-1157
Product Details | ROTARY VACUUM PUMP UNIT
4310-01-568-1157 An assembled unit consisting of a commonly mounted rotary vacuum pump(s), prime mover(s), and the necessary components to provide for a complete operation. It may include vacuum storage tank(s).
Part Alternates: U4-20, U420, 4310-01-568-1157, 01-568-1157, 4310015681157, 015681157
Pumps and Compressors | Compressors and Vacuum Pumps
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 43 | 21 OCT 2008 | 01-568-1157 | 29904 ( VACUUM PUMP UNIT, ROTARY ) |
Cross Reference | NSN 4310-01-568-1157
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| U4-20 | 1PUT9 | BECKER PUMPS CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4310-01-568-1157
Related Products | NSN 4310-01-568-1157
Technical Data | NSN 4310-01-568-1157
| Characteristic | Specifications |
|---|---|
| OVERALL HEIGHT | 8.620 INCHES NOMINAL |
| PUMPING ELEMENT TYPE | ROTARY VANE |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | OIL FLOODED VACUUM PUMP |
| INTAKE CONNECTION QUANTITY | 1 |
| INTAKE CONNECTION TYPE | BSP 1/2IN |
| PRIME MOVER TYPE | ELECTRIC MOTOR |
| OVERALL WIDTH | 9.650 INCHES NOMINAL |
| OVERALL LENGTH | 13.310 INCHES NOMINAL |
| SPECIAL FEATURES | 0.9 HORSEPOWER; 44 LBS W/MOTOR; 12.4 SCFM AT 0 IN HG FLOW; 0.5 QT OIL CAPACITY; OUTLET SIZE G3/4 IN; INCLUDES OIL SIGHT GLASS |
| VACUUM RATING | 29.9 INCHES OF MERCURY |
| DISCHARGE CONNECTION QUANTITY | 1 |
| OPERATING SPEED AT RATED CAPACITY IN RPM | 3400.0 |
| END ITEM IDENTIFICATION | LGM-30 MINUTEMAN |
| PUMP QUANTITY | 1 |
Restrictions/Controls & Freight Information | NSN 4310-01-568-1157
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 128000 | PUMPS PWR NOI/WORKING HEADS/PARTS |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | SU | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4310-01-568-1157
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Materiel Management Aggregation Code | AH | SU:LGM-30 MINUTEMAN |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | U | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
