NSN 4140-00-980-7251 MSA144093, MSA14409-3, 010405CW
Product Details | AXIAL FAN IMPELLER
4140-00-980-7251 An item with blades or vanes equally spaced radially around the periphery of a hub, flange, or rotor. It is the rotating part of an axial type fan, electric motor, generator, and the like which creates a flow of air or gas parallel to the axis of rotation.20229300045Engine Cooling System Components, Nonaircraft41400043Fans, Air Circulators, and Blower Equipment
Part Alternates: MSA144093, MSA14409-3, 010405CW, 0-1040-5CW, 4140-00-980-7251, 00-980-7251, 4140009807251, 009807251
Refrigeration, Air Conditioning, and Air Circulating Equipment | Fans, Air Circulators, and Blower Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 41 | 01 JAN 1962 | 00-980-7251 | 10087 ( IMPELLER, FAN, AXIAL ) |
Drawings & Photos | NSN 4140-00-980-7251
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4140-00-980-7251
Technical Data | NSN 4140-00-980-7251
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | 1 ROUNDED TIP |
| DIAMETER | 10.100 INCHES MAXIMUM |
| MATERIAL | ALUMINUM OVERALL |
| BLADE QUANTITY | 5 |
| MANUFACTURERS CODE | 60399 |
| DESIGN CONTROL REFERENCE | 0-1040-5CW |
Restrictions/Controls & Freight Information | NSN 4140-00-980-7251
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 127262 | PROPELLERS WHLS/FANS ETC AXIAL |
| Less than car load rating | M | 85 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72E | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
