NSN 4010-01-527-5509 670001S010106, 670-001S01-01-06, 670001S01016
Product Details | SINGLE LEG CHAIN ASSEMBLY
4010-01-527-5509 An assembly of chain(s) with attachment(s) in a continuous run from end to end. It may contain one or more intermediate and/or end attachments such as sliding or fixed ring(s), swivel(s), or hook(s), etc..
Part Alternates: 670001S010106, 670-001S01-01-06, 670001S01016, 670-001S01-01-6, 4010-01-527-5509, 01-527-5509, 4010015275509, 015275509
Rope, Cable, Chain, and Fittings | Chain and Wire Rope
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 40 | 08 FEB 2005 | 01-527-5509 | 09765 ( CHAIN ASSEMBLY, SINGLE LEG ) |
Drawings & Photos | NSN 4010-01-527-5509
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4010-01-527-5509
Technical Data | NSN 4010-01-527-5509
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL CORROSION RESISTING CHAIN |
| SURFACE TREATMENT | PASSIVATE CHAIN |
| STYLE DESIGNATOR | C4 SASH |
| OVERALL LENGTH | 0.500 FEET NOMINAL |
| SAFE OPERATING LOAD RATING | 75.0 POUNDS NOMINAL |
| FABRICATION METHOD | FORMED |
| END TYPE | TERMINAL ATTACHMENT ALL ATTACHMENTS |
| ATTACHMENT STYLE | D72 SISTER HOOK ALL ATTACHMENTS |
| SPECIAL FEATURES | TERMINAL ATTACHMENTS HAVE EYE DIAMETER OF 0.140 INCHES; CHAIN AVERAGES 100 LINKS FOR EVERY 55.5 INCHES |
| III END ITEM IDENTIFICATION | AWG9 OTPS |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | SASH CHAIN ASSEMBLY |
Restrictions/Controls & Freight Information | NSN 4010-01-527-5509
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 094050 | CHAINS NOI I/S PLAIN/GALVANIZED ETC |
| Less than car load rating | ||
| Less than truck load rating | U | 50.0 |
| Water commodity Code | 793 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | K | Clothing, including clothing equipment (other than arms and chemical supplies) cordage, fabrics and leather, parachutes, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4010-01-527-5509
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
