NSN 3950-01-285-8026 CEW224GT30D2, CEW2-24GT30D2, 01-285-8026
Product Details | WIRE ROPE HOIST
3950-01-285-8026 A device designed to be suspended above deck, floor or ground level having one or more revolving steel grooved drums around which wire rope is wound for the purpose of raising or lowering a load. May be suspended so as to travel on a fixed track.
Part Alternates: CEW224GT30D2, CEW2-24GT30D2, 3950-01-285-8026, 01-285-8026, 3950012858026, 012858026
Materials Handling Equipment | Winches, Hoists, Cranes, and Derricks
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 39 | 21 SEP 1988 | 01-285-8026 | 04588 ( HOIST, WIRE ROPE ) |
Drawings & Photos | NSN 3950-01-285-8026
Cross Reference | NSN 3950-01-285-8026
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| CEW2-24GT30D2 | 08722 | DUFF-NORTON CO INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3950-01-285-8026
Technical Data | NSN 3950-01-285-8026
| Characteristic | Specifications |
|---|---|
| OPERATION METHOD | POWER |
| PRIME MOVER TYPE | ELECTRIC MOTOR |
| PRIME MOVER QUANTITY | 1 |
| LOAD LIMIT AT SELECTED SPEED AND DRUM LOCATION | 4000.0 POUNDS SINGLE SPEED FIRST DRUM |
| TRAVEL RATE PER MINUTE | 30.0 FEET |
| BRAKING METHOD | ELECTRIC |
| HOOK QUANTITY | 2 |
| SUSPENSION MOUNTING METHOD | TROLLEY |
| TROLLEY SUSPENSION STYLE | 10 GEARED, WIDE FLANGE I BEAM, WHEELS VERTICAL |
| TROLLEY TYPE | MOTOR DRIVEN |
| MAXIMUM LIFT HEIGHT | 24.0 FEET |
| MAXIMUM LOAD RATING | 4000.0 POUNDS |
| MOUNTING POSITION | PARALLEL |
| FURNISHED ITEMS AND QUANTITY | 1 WIRE ROPE |
| MANUFACTURERS CODE | 08722 |
| DESIGN CONTROL REFERENCE | CEW2-24GT30D2 |
Restrictions/Controls & Freight Information | NSN 3950-01-285-8026
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 117040 | CHAIN/PULLEY HOISTS/BLOCKS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 793 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3950-01-285-8026
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
