NSN 3950-00-821-1764 SC12C40CB7236, SC1-2C40CB72-36, 1WG372
Product Details | WIRE ROPE HOIST
3950-00-821-1764 A device designed to be suspended above deck, floor or ground level having one or more revolving steel grooved drums around which wire rope is wound for the purpose of raising or lowering a load. May be suspended so as to travel on a fixed track.
Part Alternates: SC12C40CB7236, SC1-2C40CB72-36, 1WG372, 1WG378, 3950-00-821-1764, 00-821-1764, 3950008211764, 008211764
Materials Handling Equipment | Winches, Hoists, Cranes, and Derricks
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 39 | 01 JAN 1962 | 00-821-1764 | 04588 ( HOIST, WIRE ROPE ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3950-00-821-1764
Related Products | NSN 3950-00-821-1764
Technical Data | NSN 3950-00-821-1764
| Characteristic | Specifications |
|---|---|
| OPERATION METHOD | POWER |
| PRIME MOVER TYPE | ELECTRIC MOTOR |
| PRIME MOVER QUANTITY | 1 |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 440.0 |
| FREQUENCY IN HERTZ | 60.0 |
| PHASE | THREE |
| DUTY CYCLE | CONTINUOUS |
| INCLOSURE TYPE | PARTIALLY INCLOSED |
| ENVIRONMENTAL PROTECTION | DRIPPROOF |
| COOLING METHOD | SELF-VENTILATED |
| POWER REQUIREMENT RATING | 2.50 HORSEPOWER |
| LOAD LIMIT AT SELECTED SPEED AND DRUM LOCATION | 1000.0 POUNDS SINGLE SPEED FIRST DRUM |
| TRAVEL RATE PER MINUTE | 72.0 FEET |
| MECHANICAL ADVANTAGE METHOD | SPUR GEAR |
| HOOK QUANTITY | 1 |
| LOAD ELEMENT QUANTITY PER HOOK | 1 |
| SUSPENSION MOUNTING METHOD | BASE |
| MAXIMUM LIFT HEIGHT | 40.0 FEET |
| MOUNTING POSITION | PARALLEL |
| FURNISHED ITEMS AND QUANTITY | 1 MOTOR CONTROLLER |
| MANUFACTURERS CODE | 83299 |
| DESIGN CONTROL REFERENCE | SC1-2C40CB72-36 |
Restrictions/Controls & Freight Information | NSN 3950-00-821-1764
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 117040 | CHAIN/PULLEY HOISTS/BLOCKS |
| Less than car load rating | M | 85 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 885 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3950-00-821-1764
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 7H | Depot level reparable shipboard and base equipment, assemblies, components and repair parts related to Naval Sea Systems Command equipment Naval Inventory Control Point, Mechanicsburg |
| Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
| Agency | DN | Department of the Navy |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | H | Depot Level Reparable |
| Acquisition Advice Codes | C | SERVICE/AGENCY-MANAGED (Service/Agency use only.) # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by individual Services supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
