NSN 3940-00-151-6324 N-21-B, N21B, 3001E
Product Details | TACKLE BLOCK
3940-00-151-6324 A mechanical device, consisting of a pulley(s) or sheave(s) encased in a shell or frame which may be provided with a means such as a hook, eye, strap, screw, etc., by which it may be attached to an object. It is used to change direction of a running rope and/or to gain a mechanical advantage.
Part Alternates: N-21-B, N21B, 3001E, 3001G, 3940-00-151-6324, 00-151-6324, 3940001516324, 001516324
Materials Handling Equipment | Blocks, Tackle, Rigging, and Slings
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
39 | 16 OCT 1971 | 00-151-6324 | 06117 ( BLOCK, TACKLE ) |
Demand History | NSN 3940-00-151-6324
Part Number | Request Date | QTY | Origin |
---|---|---|---|
3001E | 2024-11-318 | 2 | US |
3940-00-151-6324 | 2017-01-24 | 48 | DIBBS |
3940-00-151-6324 | 2016-08-228 | 48 | DIBBS |
3940-00-151-6324 | 2016-08-216 | 48 | DIBBS |
3940-00-151-6324 | 2016-02-48 | 9 | DIBBS |
3940-00-151-6324 | 2016-02-34 | 9 | DIBBS |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 3940-00-151-6324
Related Products | NSN 3940-00-151-6324
Technical Data | NSN 3940-00-151-6324
Characteristic | Specifications |
---|---|
STYLE DESIGNATOR | 2 OVAL PATTERN |
SHELL LENGTH | 4.000 INCHES NOMINAL |
SHEAVE OUTSIDE DIAMETER | 2.250 INCHES NOMINAL |
CENTER PIN DIAMETER | 0.375 INCHES NOMINAL |
BLOCK TYPE | REGULAR |
MATERIAL AND LOCATION | WOOD SHELL |
SHEAVE QUANTITY | 1 |
BEARING TYPE | PLAIN |
SHEAVE BEARING LUBRICATION METHOD | SELF-LUBRICATED |
TACKLE ACCOMMODATED TYPE | FIBROUS ROPE |
MAXIMUM TACKLE DIAMETER ACCOMMODATED | 0.500 INCHES |
TACKLE LOCKING DEVICE | NOT INCLUDED |
BECKET TYPE | THIMBLE |
BECKET QUANTITY | 1 |
ANTITOPPLING DEVICE | NOT INCLUDED |
ATTACHMENT STYLE | 32 FLATTED LOOSE SWIVEL EYE WITH SWIVEL HOOK |
MAXIMUM LOAD RATING | 1000.0 POUNDS |
Restrictions/Controls & Freight Information | NSN 3940-00-151-6324
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 127300 | PULLEY BLOCKS/TCKLE/SNATCH/FAIRLDRS |
Less than car load rating | ||
Less than truck load rating | S | 60.0 |
Water commodity Code | 885 | unknown |
Originating Activity Code | 46 | Maritime Administration Washington, DC 20230 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3940-00-151-6324
Category | Code | Description |
---|---|---|
Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DF | Department of the Air Force |
Service Organization | F | U.S. Air Force |
Reparability | N | Stock Fund (except Munitions) |
Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
