NSN 3230-01-298-4495 R-200, R200, 01-298-4495
Product Details | FRAME ASSEMBLY TABLE
3230-01-298-4495 A table designed to align frame parts for smooth construction of all types of wood, plywood frames, plastic covered frames or particle board regardless of thickness of material. Item may or may not be equipped with a drill unit.
Part Alternates: R-200, R200, 3230-01-298-4495, 01-298-4495, 3230012984495, 012984495
Woodworking Machinery and Equipment | Tools and Attachments for Woodworking Machinery
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 32 | 01-298-4495 | 41842 ( TABLE, FRAME ASSEMBLY ) |
Drawings & Photos | NSN 3230-01-298-4495
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3230-01-298-4495
Technical Data | NSN 3230-01-298-4495
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 144.000 INCHES NOMINAL |
| OVERALL WIDTH | 5.000 INCHES NOMINAL |
| OPERATION METHOD | POWERED |
| VENIER SCALE | NOT INCLUDED |
| TILTING FEATURE | NOT INCLUDED |
| SPECIAL FEATURES | INCLUDES CLAMP BEAM W/5 CLAMP CYLINDERS AND SINGLE SPINDLE DRILL TUB,FOOT ACTUATED,3/4 HP AND 110 VOLTS,WEIGHT APPROXIMATELY 1600 LBS |
| MANUFACTURERS CODE | 0AKX4 |
| DESIGN CONTROL REFERENCE | R-200 |
Restrictions/Controls & Freight Information | NSN 3230-01-298-4495
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
