NSN 3220-01-038-2457 GGGS0058STYLEBSIZE16, GGG-S-0058STYLEBSIZE16, 01-038-2457
Product Details | TRAILER MOUNTED WOODWORKING RADIAL OVERARM SAW
3220-01-038-2457 A mobile unit containing a diesel or gasoline engine powered electric generator and a SAW, RADIAL OVERARM, WOODWORKING with a power feed. It may include various cutters, metal cutting circular saw blade(s), conveyor(s), power driven hand tools, miscellaneous hand tools, and the like.
Part Alternates: GGGS0058STYLEBSIZE16, GGG-S-0058STYLEBSIZE16, 3220-01-038-2457, 01-038-2457, 3220010382457, 010382457
Woodworking Machinery and Equipment | Woodworking Machines
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 32 | 01 APR 1977 | 01-038-2457 | 20775 ( SAW, RADIAL OVERARM, WOODWORKING, TRAILER MOUNTED ) |
Cross Reference | NSN 3220-01-038-2457
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| GGG-S-0058STYLEBSIZE16 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3220-01-038-2457
Related Products | NSN 3220-01-038-2457
Technical Data | NSN 3220-01-038-2457
| Characteristic | Specifications |
|---|---|
| BLADE MAXIMUM DIAMETER ACCOMMODATED | 16.000 INCHES |
| BLADE ARBOR DIAMETER ACCOMMODATED | 1.000 INCHES NOMINAL |
| CUTOFF CAPACITY | 1 IN.THK AND 24 IN.W |
| MAXIMUM RIPPING CAPACITY | 36.000 INCHES |
| ELECTRIC GENERATOR POWER METHOD | DIESEL ENGINE |
| TIRE TYPE | PNEUMATIC |
| SIZE DESIGNATION | 9.00-20 |
| RETRACTABLE TRAILER SUPPORT | NOT PROVIDED |
| SUPPLY ITEMS AND QUANTITIES | 2330-00-728-0262,TRAILER,CARGO,1 |
| DOCUMENT CONTROLLING AGENCY | ARMY |
| DOCUMENT TYPE | MILITARY SPECIFICATION |
| DOCUMENT IDENTIFICATION | MIL-S-17717C |
| COMPONENT DOCUMENT PAGE NUMBER | 6 |
| SPECIAL FEATURES | SAW HAS ROLLERS FOR ROLLING SAW FROM TRAILER ONTO TAILGATE AND BACK WITHOUT BINDING,HOLD-DOWN BRACKETS PREVENT SAW FROM SHIFTING; WITH TWO HANDLES IAW MS35792-1,ARROR IS INTEGRAL PART OF MOTOR SHAFT,MODIFIED FOR TRAILER MOUNTING |
| MANUFACTURERS CODE | 81348 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | GGG-S-0058STYLEBSIZE16 |
Restrictions/Controls & Freight Information | NSN 3220-01-038-2457
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Controlled Inventory Item Code: | M | HANDTOOLS AND SHOP EQUIPMENT |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | N | The item does not have a critical feature such as tolerance, fit restrictions or application. Nuclear hardness properties have not been determined (not valid for input). |
| Category | Code | Description |
|---|---|---|
| NMF Description | 131670 | TOOLS PWR O/T PWR HND TOOLS |
| Less than car load rating | W | Rating Variable |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72E | unknown |
| Originating Activity Code | AJ | U.S. Army Soldier's Biological and Chemical Command Natick, MA 01760 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | FF | |
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3220-01-038-2457
Army| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | M | Ammunition weapons, and tracked combat vehicles weapons, special weapons, chemical and fire control materiel |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 1 | REPARABLE ITEMS (Exclusive of Insurance and Provisioning Items.) This code will be used to identify serviceable or unserviceable items of a durable nature which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance. |
| Specific Group/Generic Code | W | Line of Communication/Base Support Systems |
| Weapons Systems/End Item or Homogeneous Group | WU | Tool Sets and Miscellaneous Sets, Kits and Outfits |
| Accounting Requirements Code | N | Nonexpendable item. An item of Army property coded with an ARC of?N?in the AMDF. Nonexpendable items require property book accountability after issue from the stock record account. Commercial and fabricated items similar to items coded ?N? in the AMDF are considered nonexpendable items. |
| Source of Supply | B14 | US Army Armament and Chemical Acquisition and Logistics Activity ATTN: AMSTA-AC Rock Island, IL 61299-6000 |
| Agency | DA | Department of the Army |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | F | If condemned or uneconomically repairable, then dispose at Direct Support (DS) level. |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | M | HANDTOOLS AND SHOP EQUIPMENT |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
