NSN 3220-00-490-9321 382, 00-490-9321, 004909321
Product Details | DISK SANDER
3220-00-490-9321 A fixed wood surface finishing machine having a direct motor driven spindle or spindles on which is mounted a steel disk for attaching abrasive paper. A removable table is provided with the hinged side adjacent to the disk and is capable of adjustment to 45 degree (0.8 radians) angle and also vertically to clear the disk entirely.
Part Alternates: 382, 3220-00-490-9321, 00-490-9321, 3220004909321, 004909321
Woodworking Machinery and Equipment | Woodworking Machines
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 32 | 01 JAN 1963 | 00-490-9321 | 08043 ( SANDER, DISK ) |
Drawings & Photos | NSN 3220-00-490-9321
Demand History | NSN 3220-00-490-9321
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 382 | 2018-07-184 | 300 | US |
| 382 | 2018-04-101 | 20 | US |
Cross Reference | NSN 3220-00-490-9321
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 382 | 44769 | OLIVER MACHINERY CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3220-00-490-9321
Related Products | NSN 3220-00-490-9321
Technical Data | NSN 3220-00-490-9321
| Characteristic | Specifications |
|---|---|
| MOUNTING TYPE | FLOOR SURFACE, FREE STANDING |
| DISK TYPE | DOUBLE |
| DISK DIAMETER | 20.000 INCHES NOMINAL |
| DISK TABLE LENGTH | 25.000 INCHES NOMINAL |
| DISK TABLE WIDTH | 12.250 INCHES NOMINAL |
| DISK TABLE DOWNWARD TILT ANGLE IN DEG | 45.0 |
| DISK TABLE UPWARD TILT ANGLE IN DEG | 25.0 |
| DISK TABLE LATERAL ADJUSTMENT | 2.750 INCHES NOMINAL |
| DRIVE METHOD | ELECTRIC MOTOR |
| CURRENT TYPE | AC |
| VOLTAGE IN VOLTS | 220.0 |
| FREQUENCY IN HERTZ | 60.0 |
| PHASE | THREE |
| PRIME MOVER HORSEPOWER RATING | 2.0 |
| MANUFACTURERS CODE | 44769 |
| DESIGN CONTROL REFERENCE | 382 |
Restrictions/Controls & Freight Information | NSN 3220-00-490-9321
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI SUB 2 |
| Less than car load rating | ||
| Less than truck load rating | K | 92.5 |
| Water commodity Code | 72E | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3220-00-490-9321
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | PD | Regulated items, item manager controlled. |
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | U | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | X | SEMIACTIVE ITEM-NO REPLACEMENT (NON-STOCKED ITEMS) A potentially inactive NSN which must be retained in the supply system as an item of supply because (1) stocks of the item are on hand or in use below the wholesale level and (2) the NSN is cited in equipment authorization documents TO & E, TA, TM, etc., or in-use assets are being reported. 1. Items are authorized for central procurement but not authorized for stockage at wholesale level. 2. Requisitions for in-use replacement will be authorized in accordance with individual Military Service directives. 3. Requisitions may be submitted as requirements generate. Repetitive demands may dictate an AAC change to permit wholesale stockage. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
