NSN 3120-01-576-5034 NAS77A4013, NAS77A4-013, 01-576-5034
Product Details | SLEEVE BUSHING
3120-01-576-5034 A tubular shaped unthreaded item with or without a flange at one end designed to be inserted into a hole to reduce the inside diameter of the hole and to protect the surrounding body structure from damage resulting from stress, strain, and/or vibration. The overall length must exceed 25 percent of the outside diameter or the shortest distance between peripheral flats of the body. Includes items which are divided into two or more segments which includes 180 degrees (3.141 radians) or less of the bearing periphery. For items made of rubber, see BUSHING, NONMETALLIC. See also BEARING, SLEEVE; BUSHING, TAPERED; SPACER, SLEEVE; INSULATOR, BUSHING; and BUSHING, ELECTRICAL CONDUCTOR. Excludes BUSHING, DRILL, JIG.20231200026Bearings, Plain, Unmounted53650035Bushings, Rings, Shims, and Spacers
Part Alternates: NAS77A4013, NAS77A4-013, 3120-01-576-5034, 01-576-5034, 3120015765034, 015765034
Bearings | Bearings, Plain, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 03 AUG 2009 | 01-576-5034 | 13206 ( BUSHING, SLEEVE ) |
Drawings & Photos | NSN 3120-01-576-5034
Demand History | NSN 3120-01-576-5034
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| NAS77A4013 | 2016-03-70 | 50 | United States |
| NAS77A4013 | 2015-12-343 | 50 | United States |
| NAS77A4013 | 2015-12-343 | 100 | United States |
| NAS77A4013 | 2015-06-167 | 24 | United States |
| NAS77A4013 | 2011-06-157 | 3 | US |
| NAS77A4013 | 2010-09-253 | 15 | United States |
| 3120-01-576-5034 | 2009-10-295 | 250 | DIBBS |
Cross Reference | NSN 3120-01-576-5034
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| NAS77A4-013 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
