NSN 3110-01-099-2295 01-099-2295, 010992295
Product Details | BEARING RETAINING PLATE
3110-01-099-2295 A comparatively flat rigid item, with or without a centrally located aperture, designed to hold an annular bearing or a sleeve bearing in a fitted inclosure. It must have drilled and/or tapped holes for mounting purposes. Excludes END BELL, ELECTRICAL ROTATING EQUIPMENT.
Part Alternates: 3110-01-099-2295, 01-099-2295, 3110010992295, 010992295
Bearings | Bearings, Antifriction, Unmounted
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
31 | 01-099-2295 | 22293 ( PLATE, RETAINING, BEARING ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 3110-01-099-2295
Related Products | NSN 3110-01-099-2295
Technical Data | NSN 3110-01-099-2295
Characteristic | Specifications |
---|---|
MATERIAL | ALUMINUM ALLOY 2024 OVERALL |
SURFACE TREATMENT | CHROMATE OVERALL |
WIDTH | 1.190 INCHES NOMINAL |
LENGTH | 2.690 INCHES NOMINAL |
APERTURE DIAMETER | 0.625 INCHES MINIMUM AND 0.626 INCHES MAXIMUM |
RAISED SURFACE HEIGHT | 0.340 INCHES NOMINAL |
MANUFACTURERS CODE | 12511 |
DESIGN CONTROL REFERENCE | A51417 |
Restrictions/Controls & Freight Information | NSN 3110-01-099-2295
Category | Code | Description |
---|---|---|
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Category | Code | Description |
---|---|---|
No Freight Information |
