NSN 3110-00-155-9601 ND77R3, R31PP, R31PPK25
Product Details | ANNULAR BALL BEARING
3110-00-155-9601 A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME.
Part Alternates: ND77R3, R31PP, R31PPK25, RL3264, T9379RL3264, EEB12Z, EEB1-2Z, FFB171, 01120304, 01-12-03-04, 0583, 058-3, 10107344 , 177597, 3091410000, 309-1410-000, 319687-423, 33DD5, 33KDD5E4816, 3H30523, 3H305-23, 4666FF, 583, 58-3, 66785, 701061, 7501029, 750-1029, 77R3X1266CP27, 77R3X1E, 9191275, 98W60, 3110-00-155-9601, 00-155-9601, 3110001559601, 001559601, 319687423
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 01 JAN 1963 | 00-155-9601 | 00014 ( BEARING, BALL, ANNULAR ) |
Drawings & Photos | NSN 3110-00-155-9601
Demand History | NSN 3110-00-155-9601
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 583 | 2019-10-294 | 2 | United States |
| 3110-00-155-9601 | 2018-08-220 | 5 | BE |
| 3110-00-155-9601 | 2018-08-213 | 5 | BE |
| FFB171 | 2017-01-10 | 7 | US |
| FFB171 | 2013-01-11 | 22 | US |
| FFB171 | 2008-11-317 | 8 | United States |
Cross Reference | NSN 3110-00-155-9601
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 01-12-03-04 | 92755 | NORTHROP GRUMMAN SYSTEMS CORPORATION DBA LAND & SELF PROTECTION SYSTEM |
| 058-3 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 177597 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 309-1410-000 | 13499 | ROCKWELL COLLINS, INC. DBA GOVERNMENT SYSTEMS |
| 319687-423 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 33DD5 | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| 33KDD5E4816 | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| 3H305-23 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
| 4666FF | 38443 | SKF USA INC DBA SKF AEROENGINE NORTH AMERICA |
| 58-3 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 66785 | 10237 | CADILLAC GAGE TEXTRON INC. |
| 701061 | 21450 | ARMY WEAPONS COMMAND ATTN AMSWE-REE-S |
| 750-1029 | 62143 | NORTHERN TELECOM INC TELECOM DISTRIBUTION DIV |
| 750-1029 | 71688 | NORTHERN TELECOM INC COOK ELECTRIC DIV |
| 77R3X1266CP27 | 24617 | GENERAL MOTORS CORP |
| 77R3X1266CP27 | 43334 | GENERAL MOTORS CORP DELCO MORAINE NDH DIV |
| 77R3X1E | 43334 | GENERAL MOTORS CORP DELCO MORAINE NDH DIV |
| 9191275 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 98W60 | 02205 | UNION CARBIDE CORP LINDE DIV |
| EEB1-2Z | 52676 | SKF USA INC. |
| FFB171 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| ND77R3 | 43334 | GENERAL MOTORS CORP DELCO MORAINE NDH DIV |
| R31PP | 83086 | NEW HAMPSHIRE BALL BEARINGS, INC. DIV HITECH DIVISION |
| R31PPK25 | 83086 | NEW HAMPSHIRE BALL BEARINGS, INC. DIV HITECH DIVISION |
| RL3264 | 88818 | KEARFOTT CORPORATION DBA KEARFOTT |
| T9379RL3264 | 56167 | BUREAU OF AERONAUTICS SPECIAL DEVICES DIV |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3110-00-155-9601
Technical Data | NSN 3110-00-155-9601
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| STYLE DESIGNATOR | 10A NON-LOADING GROOVE, NON-SEPARABLE |
| OVERALL WIDTH | 0.1960 INCHES NOMINAL |
| BORE DIAMETER | 0.1875 INCHES NOMINAL |
| OVERALL OUTSIDE DIAMETER | 0.5000 INCHES NOMINAL |
| LUBRICATION MATERIAL | GREASE |
| LUBRICATION MATERIAL DOCUMENT AND CLASSIFICATION | MIL-G-18709 MIL SPEC SINGLE MATERIAL RESPONSE |
| STANDARD TOLERANCE DESIGNATION | ABEC NO.1 |
| BORE SHAPE | STRAIGHT |
| SURFACE FINISH | GROUND |
| RETAINER FABRICATION METHOD | PRESSED |
| SHIELD QUANTITY | 2 |
| LOAD DIRECTION | RADIAL |
| INTERNAL FIT-UP DESIGNATION | STANDARD |
| NONDEFINITIVE SPEC/STD DATA | 115 TYPE AND 00 GRADE |
| DEPARTURE FROM CITED DESIGNATOR | AS MODIFIED BY OVERALL WIDTH,AS MODIFIED BY SHIELD QUANTITY |
| MANUFACTURERS CODE | 81348 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | FFB171 |
Restrictions/Controls & Freight Information | NSN 3110-00-155-9601
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 3110-00-155-9601
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9Z | Navy-owned stocks of defense industrial material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9I | Defense Industrial Supply Center Philadelphia, PA 19111 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
