NSN 3110-00-144-8482 C95BB, C95TF, FFB171
Product Details | ANNULAR BALL BEARING
3110-00-144-8482 A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME.
Part Alternates: C95BB, C95TF, FFB171, FF-B-171/01-J35A2E, FF-B-171/1, FFB17101J35A2E, FFB1711, PPC95, VJ452, X38013, X380-13, R5, T35, 72-6970-231, 79044, 89022, 8902-2, 9431, C95, M8, 3196872, 319687-2, 35, 35ABEC1, 35J, 35K, 35X1, 35X1A, 515193, 5523, 5BC03, 635CE1TX9, 0592, 059-2, 10810, 12, 1210294, 121029-4, 1223575, 122357-5, 12Z31576, 12Z315-76, 1770022, 177002-2, 18, 180028A, 200183, 22, 2738292, 273829-2, 28, 2800262, 280026-2, 28147872, 281478-72, 2E81, 2E89, 2E90, 3110-00-144-8482, 00-144-8482, 3110001448482, 726970231, 001448482
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 01 JAN 1961 | 00-144-8482 | 00014 ( BEARING, BALL, ANNULAR ) |
Drawings & Photos | NSN 3110-00-144-8482
Demand History | NSN 3110-00-144-8482
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 18 | 2020-12-18 | 0 | |
| 5523 | 2020-04-27 | 8 | United Arab Emirates |
| 22 | 2019-02-10 | 1 | US |
| 22 | 2019-02-07 | 1 | US |
| FFB171 | 2017-01-10 | 7 | US |
| 22 | 2016-07-27 | 12 | us |
| R5 | 2015-11-03 | 97 | United States |
| 3110-00-144-8482 | 2015-07-28 | 159 | DIBBS |
| 3110-00-144-8482 | 2015-04-15 | 159 | DIBBS |
| 3110-00-144-8482 | 2014-11-13 | 159 | DIBBS |
| 3110-00-144-8482 | 2014-11-10 | 159 | DIBBS |
| FFB171 | 2013-01-11 | 22 | US |
| FFB171 | 2008-11-12 | 8 | United States |
| 180028A | 2006-08-01 | 6 | Portugal |
| 635CE1TX9 | 2006-08-01 | 8 | Portugal |
Cross Reference | NSN 3110-00-144-8482
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 059-2 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 10810 | 1PQF4 | L-3 COMMUNICATIONS CORPORATION DBA LINK SIMULATION & TRAINING |
| 10810 | 36378 | RAYTHEON TECHNICAL SERVICES COMPANY |
| 12 | 39899 | A B SEALS INC DBA CAST SEAL TYPE A AND TYPE B |
| 121029-4 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 122357-5 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 12Z315-76 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 177002-2 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 18 | 39899 | A B SEALS INC DBA CAST SEAL TYPE A AND TYPE B |
| 180028A | 31361 | WOODWARD, INC. DBA INDUSTRIAL PRODUCTS GROUP |
| 180028A | 66503 | WOODWARD, INC. DBA WOODWARD |
| 180028A | 82796 | COLTEC INDUSTRIES INC DBA FAIRBANKS MORSE ENGINE |
| 200183 | 56232 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN |
| 22 | 39899 | A B SEALS INC DBA CAST SEAL TYPE A AND TYPE B |
| 273829-2 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 28 | 39899 | A B SEALS INC DBA CAST SEAL TYPE A AND TYPE B |
| 280026-2 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 281478-72 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 2E81 | 01FK3 | OERLIKON METCO (US) INC. |
| 2E81 | 39918 | METCO INC SUB OF THE PERKIN-ELMER CORP |
| 2E89 | 01FK3 | OERLIKON METCO (US) INC. |
| 2E89 | 39918 | METCO INC SUB OF THE PERKIN-ELMER CORP |
| 2E90 | 01FK3 | OERLIKON METCO (US) INC. |
| 2E90 | 39918 | METCO INC SUB OF THE PERKIN-ELMER CORP |
| 319687-2 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 35 | 39317 | MCGILL MANUFACTURING COMPANY INC USE CAGE CODE 92563 FOR CATALOGING. |
| 35 | 52676 | SKF USA INC. |
| 35 | 82634 | MCGILL MFG CO INC ELECTRICAL DIV |
| 35ABEC1 | 38443 | SKF USA INC DBA SKF AEROENGINE NORTH AMERICA |
| 35J | 52676 | SKF USA INC. |
| 35K | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| 35X1 | 24617 | GENERAL MOTORS CORP |
| 35X1 | 43334 | GENERAL MOTORS CORP DELCO MORAINE NDH DIV |
| 35X1A | 24617 | GENERAL MOTORS CORP |
| 35X1A | 43334 | GENERAL MOTORS CORP DELCO MORAINE NDH DIV |
| 515193 | 23667 | SMITHS DETECTION, INC. DIV EDGEWOOD |
| 5523 | 55948 | BOTOMAN MFG CO INC |
| 5BC03 | 70413 | ANTI-FRICTION BEARING MFG ASSN INC THE |
| 635CE1TX9 | 53035 | NSK CORP BEARING DIV |
| 72-6970-231 | 50024 | COLTEC INDUSTRIES INC DBA FAIRBANKS MORSE ENGINE FM/ALCO |
| 79044 | 06840 | BENDIX CORP THE |
| 79044 | 06848 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 8902-2 | 03848 | ARMA DIV AMBAC INDUSTRIES INC |
| 9431 | 21760 | SCHATZ BEARING CORPORATION |
| C95 | 43991 | FAG BEARINGS CORPORATION |
| C95 | 49481 | QUALITY ELECTRIC CO |
| C95BB | 49481 | QUALITY ELECTRIC CO |
| C95TF | 43991 | FAG BEARINGS CORPORATION |
| FF-B-171/01-J35A2E | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| FF-B-171/1 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| FFB171 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| M8 | 39899 | A B SEALS INC DBA CAST SEAL TYPE A AND TYPE B |
| PPC95 | 51261 | CONTRAVES INC |
| R5 | 52676 | SKF USA INC. |
| T35 | 60380 | TIMKEN AEROSPACE, INC DBA TORRINGTON PRODUCT |
| VJ452 | 08484 | BREEZE-EASTERN CORPORATION |
| X380-13 | 99167 | HAMILTON SUNDSTRAND CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3110-00-144-8482
Related Products | NSN 3110-00-144-8482
Technical Data | NSN 3110-00-144-8482
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL OVERALL |
| STYLE DESIGNATOR | 10A NON-LOADING GROOVE, NON-SEPARABLE |
| OVERALL WIDTH | 6.0 MILLIMETERS NOMINAL |
| BORE DIAMETER | 5.00 MILLIMETERS NOMINAL |
| OVERALL OUTSIDE DIAMETER | 19.00 MILLIMETERS NOMINAL |
| STANDARD TOLERANCE DESIGNATION | ABEC NO.1 |
| BORE SHAPE | STRAIGHT |
| SURFACE FINISH | GROUND |
| RETAINER FABRICATION METHOD | PRESSED |
| LOAD DIRECTION | RADIAL |
| INTERNAL FIT-UP DESIGNATION | STANDARD |
| NONDEFINITIVE SPEC/STD DATA | 111 TYPE AND 1 CLASS AND 00 GRADE |
| MANUFACTURERS CODE | 81348 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | FF-B-171/01-J35A2E |
| MANUFACTURERS CODE | 81348 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | FF-B-171/1 |
Restrictions/Controls & Freight Information | NSN 3110-00-144-8482
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114820 | BEARINGS/BUSHINGS NOI BALL/ROLLER |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3110-00-144-8482
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | T | Industrial Supplies (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
