Product Details | TAPERED ROLLER BEARING

3110-00-100-4404 A cylindrical device in which the inner cone or outer cup turns upon a single or double row of tapered hardened rollers which roll easily in a race, thus minimizing friction and designed to carry a radial load and capable of sustaining axial thrust. Excludes BEARING, ROLLER, THRUST.

Part Alternates: MS19081255, MS19081-255, FFB187, FF-B-187, FF-B-187/01-538, FF-B-187/1, FFB18701538, FFB1871, 12C30, 5180658, 5556156, 5556158, 58, 59, 705184, 745A, 745A742, 31000-0068, 3110-00-100-4404, 00-100-4404, 3110001004404, 001004404, 310000068

Bearings | Bearings, Antifriction, Unmounted

Supply Group (FSG) NSN Assign. NIIN
31 01 JAN 1961 00-100-4404

Drawings & Photos | NSN 3110-00-100-4404


Demand History | NSN 3110-00-100-4404

Part Number Request Date QTY Origin
3110-00-100-4404 2008-09-255 8 US

Cross Reference | NSN 3110-00-100-4404

Part Number Cage Code Manufacturer
12C30 24047 COOPER INDUSTRIES INC DBA COOPER TOOLS
12C30 6X081 COOPER INDUSTRIES INDUSTRIAL MACHINERY DIV
31000-0068 17454 TIMKEN GEARS & SERVICES INC. DBA PHILADELPHIA GEAR
5180658 96722 MOFFET ENGINEERING CO
5556156 55102 CONTINENTAL EMSCO CO SKAGIT PRODUCTS DIV
5556158 55102 CONTINENTAL EMSCO CO SKAGIT PRODUCTS DIV
58 34640 LA CROSSE TRAILER CORP
59 34640 LA CROSSE TRAILER CORP
705184 21450 ARMY WEAPONS COMMAND ATTN AMSWE-REE-S
745A 51588 RBC BEARINGS INCORPORATED DIV WEST TRENTON DIVISION
745A 53035 NSK CORP BEARING DIV
745A742 01212 FEDERAL-MOGUL CORP GOVERNMENT SALES DEPT
745A742 55102 CONTINENTAL EMSCO CO SKAGIT PRODUCTS DIV
745A742 60038 TIMKEN CORPORATION, THE
FF-B-187 81348 FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES
FF-B-187/01-538 96906 MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS
FF-B-187/1 81348 FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES
MS19081-255 96906 MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 3110-00-100-4404

Technical Data | NSN 3110-00-100-4404

Characteristic Specifications
MATERIAL STEEL CONE STEEL CUP STEEL RETAINER STEEL ROLLER
MATERIAL DOCUMENT AND CLASSIFICATION 66 FED STD SINGLE MATERIAL RESPONSE CONE 66 FED STD SINGLE MATERIAL RESPONSE CUP 66 FED STD SINGLE MATERIAL RESPONSE ROLLER
STYLE DESIGNATOR 350 STRAIGHT BORE, NORMAL ANGLE
OVERALL WIDTH 1.7500 INCHES NOMINAL
BORE DIAMETER 2.7500 INCHES NOMINAL
OVERALL OUTSIDE DIAMETER 5.9090 INCHES NOMINAL
BACKFACE CORNER RADIUS 0.1300 INCHES NOMINAL
STANDOUT WIDTH 0.3125 INCHES NOMINAL
CONE CORNER RADIUS 0.1400 INCHES NOMINAL
CONE WIDTH 1.8375 INCHES NOMINAL
CUP WIDTH 1.4375 INCHES NOMINAL
STANDARD TOLERANCE DESIGNATION AFBMA CLASS 4
RETAINER FABRICATION METHOD PRESSED
MANUFACTURERS CODE 96906
DEFINITIVE GOVERNMENT SPEC/STD REFERENCE FF-B-187/01-538
MANUFACTURERS CODE 81348
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE FF-B-187/1

Restrictions/Controls & Freight Information | NSN 3110-00-100-4404

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 114820 BEARINGS/BUSHINGS NOI BALL/ROLLER
Less than car load rating
Less than truck load rating P 77.5
Water commodity Code 742 unknown
Originating Activity Code XX
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 3110-00-100-4404

Category Code Description
Materiel Category and Inventory ManagerT Industrial Supplies (DLA/GSA Items)
Appropriation and Budget Activity2 Stock Fund Secondary Items
Management Inventory Segment2 NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable.
Specific Group/Generic Code0 Medical Materiel
Weapons Systems/End Item or Homogeneous Group00DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
Accounting Requirements CodeX Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDADepartment of the Army
Service OrganizationAU.S. Army
ReparabilityZThis is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item.
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Budget Code9 General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors.
Fund CodeSFStock fund applicable to items managed for the Air Force by the respective Inventory Control Point.
Price ValidationV The current standard price has been validated.
  • The item has been analyzed in conjunction with the Zero Overpricing Program and is in the accepted price range.
  • The item was procured under open competition and under the competitive arena the price is considered fair and reasonable.
  • ZOP or Standard price challenges are permissible but must be supported by adequate justification.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDFDepartment of the Air Force
Service OrganizationFU.S. Air Force
ReparabilityNStock Fund (except Munitions)
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Stores Account Code1Marine Corps Stock Fund Account Item.
Combat Essentiality Code5Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency.
Materiel Management CodeBAll CommoditiesDefense Logistics Agency, (DLA,)
Echelon Management Code2ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled.
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDMU.S. Marine Corps
Service OrganizationMU.S. Marine Corps
ReparabilityZNonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code.
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
