NSN 3110-00-067-9990 MS9241264, MS9241-264 , AS3551264
Product Details | ANNULAR BALL BEARING
3110-00-067-9990 A cylindrical device in which the inner or outer ring turns upon a single or double row of hardened balls which roll easily between the two rings, thus minimizing friction. For items with faces specially ground for duplex mounting see BEARING, BALL, DUPLEX. Excludes BEARING, BALL, AIRFRAME.
Part Alternates: MS9241264, MS9241-264 , AS3551264, AS3551-264 , SR166PPDC14K58, SR186SSWX12K5VL, D505, 13798702, 137987-02, 15863801, 158638-01, 30434, 4655661, 465566-1, 3110-00-067-9990, 00-067-9990, 3110000679990, 000679990
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 11 JUL 1967 | 00-067-9990 | 00014 ( BEARING, BALL, ANNULAR ) |
Drawings & Photos | NSN 3110-00-067-9990
Demand History | NSN 3110-00-067-9990
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 137987-02 | 2024-09-255 | 1231 | DIBBS |
| 137987-02 | 2024-09-247 | 1231 | DIBBS |
| 137987-02 | 2024-06-161 | 511 | DIBBS |
| 137987-02 | 2024-02-53 | 620 | DIBBS |
| 137987-02 | 2024-01-30 | 17 | DIBBS |
| 137987-02 | 2024-01-23 | 4 | DIBBS |
| 137987-02 | 2023-12-347 | 28 | DIBBS |
| 137987-02 | 2023-11-330 | 33 | DIBBS |
| 137987-02 | 2023-11-323 | 2 | DIBBS |
| 137987-02 | 2023-09-270 | 2 | DIBBS |
| 137987-02 | 2023-07-183 | 619 | DIBBS |
| 137987-02 | 2023-03-85 | 48 | DIBBS |
| 3110-00-067-9990 | 2020-10-304 | 1 | DIBBS-RFPs |
| 3110-00-067-9990 | 2017-03-66 | 12 | Spain |
| 3110-00-067-9990 | 2016-11-315 | 721 | DIBBS |
| 13798702 | 2016-10-300 | 50 | Italy |
| 3110-00-067-9990 | 2016-10-288 | 1 | DIBBS-RFPs |
| 3110-00-067-9990 | 2016-09-263 | 384 | DIBBS |
| 3110-00-067-9990 | 2016-04-96 | 1663 | DIBBS |
| 3110-00-067-9990 | 2015-12-341 | 1663 | DIBBS |
| 3110-00-067-9990 | 2015-08-216 | 408 | DIBBS |
| 3110-00-067-9990 | 2015-07-203 | 408 | DIBBS |
| 3110-00-067-9990 | 2015-02-37 | 581 | DIBBS |
| 3110-00-067-9990 | 2014-11-316 | 580 | DIBBS |
| 3110-00-067-9990 | 2014-05-136 | 2456 | DIBBS |
| 3110-00-067-9990 | 2014-05-125 | 2456 | DIBBS |
| 3110-00-067-9990 | 2014-04-105 | 730 | DIBBS |
| 3110-00-067-9990 | 2013-09-255 | 1620 | DIBBS |
| 3110-00-067-9990 | 2013-07-196 | 978 | DIBBS |
| 3110-00-067-9990 | 2011-06-159 | 2232 | DIBBS |
| 3110-00-067-9990 | 2011-05-138 | 3067 | DIBBS |
| 3110-00-067-9990 | 2011-04-110 | 2115 | DIBBS |
| 3110-00-067-9990 | 2011-04-110 | 2425 | DIBBS |
| 3110-00-067-9990 | 2011-03-67 | 2424 | DIBBS |
| 3110-00-067-9990 | 2011-02-45 | 2115 | DIBBS |
| 3110-00-067-9990 | 2010-05-131 | 3039 | DIBBS |
| 3110-00-067-9990 | 2010-04-102 | 3039 | DIBBS |
| SR186SSWX12K5VL | 2010-03-84 | 250 | US |
| 3110-00-067-9990 | 2009-10-280 | 3129 | DIBBS |
| 3110-00-067-9990 | 2009-09-261 | 400 | Turkey |
| 3110-00-067-9990 | 2009-09-261 | 400 | Turkey |
| 3110-00-067-9990 | 2009-08-216 | 1322 | DIBBS |
| 3110-00-067-9990 | 2009-05-149 | 100 | us |
| 3110-00-067-9990 | 2009-05-140 | 146 | DIBBS |
| 3110-00-067-9990 | 2009-03-69 | 15598 | DIBBS |
| 3110-00-067-9990 | 2009-02-56 | 15598 | DIBBS |
| 3110-00-067-9990 | 2008-04-99 | 1590 | DIBBS |
| 3110-00-067-9990 | 2007-06-177 | 4704 | DIBBS |
Cross Reference | NSN 3110-00-067-9990
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 137987-02 | 35351 | GE AVIATION SYSTEMS LLC |
| 137987-02 | 40920 | MPB CORPORATION DBA TIMKEN SUPER PRECISION |
| 137987-02 | 50294 | NEW HAMPSHIRE BALL BEARINGS, INC. DBA NHBB |
| 137987-02 | 70854 | BARDEN CORPORATION, THE DIV BARDEN PRECISION BEARINGS |
| 137987-02 | 83086 | NEW HAMPSHIRE BALL BEARINGS, INC. DIV HITECH DIVISION |
| 158638-01 | 35351 | GE AVIATION SYSTEMS LLC |
| 30434 | 50027 | FLIGHTLINE ELECTRONICS, INC. DBA ULTRA ELEC FLIGHTLINE SYSTEMS |
| 465566-1 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
| D505 | 40920 | MPB CORPORATION DBA TIMKEN SUPER PRECISION |
| SR166PPDC14K58 | 83086 | NEW HAMPSHIRE BALL BEARINGS, INC. DIV HITECH DIVISION |
| SR186SSWX12K5VL | 70854 | BARDEN CORPORATION, THE DIV BARDEN PRECISION BEARINGS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3110-00-067-9990
Related Products | NSN 3110-00-067-9990
Technical Data | NSN 3110-00-067-9990
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 440C BALL STEEL COMP 440C INNER RING STEEL COMP 440C OUTER RING STEEL CORROSION RESISTING RETAINER STEEL CORROSION RESISTING SHIELD |
| MATERIAL DOCUMENT AND CLASSIFICATION | AISI ASSN STD SINGLE MATERIAL RESPONSE BALL AISI ASSN STD SINGLE MATERIAL RESPONSE INNER RING AISI ASSN STD SINGLE MATERIAL RESPONSE OUTER RING |
| STYLE DESIGNATOR | 10A NON-LOADING GROOVE, NON-SEPARABLE |
| OVERALL WIDTH | 0.1562 INCHES NOMINAL |
| BORE DIAMETER | 0.1875 INCHES NOMINAL |
| OVERALL OUTSIDE DIAMETER | 0.5000 INCHES NOMINAL |
| LUBRICATION MATERIAL | OIL |
| LUBRICATION MATERIAL DOCUMENT AND CLASSIFICATION | MIL-L-6085 MIL SPEC SINGLE MATERIAL RESPONSE |
| STANDARD TOLERANCE DESIGNATION | ABEC NO.5 |
| BORE SHAPE | STRAIGHT |
| SURFACE FINISH | GROUND |
| RETAINER FABRICATION METHOD | PRESSED |
| SHIELD QUANTITY | 2 |
| LOAD DIRECTION | RADIAL |
| INTERNAL CLEARANCE | 0.0005 INCHES MINIMUM RADIAL AND 0.0008 INCHES MAXIMUM RADIAL |
| SPECIAL FEATURES | STARTING TORQUE 4400 WAX GM MM AT 400 GM THRUST LOAD AND RADIAL TORQUE 300 MAX MG MM ALSO RACE CURVATURE 52.0 TO 58.0PCT |
Restrictions/Controls & Freight Information | NSN 3110-00-067-9990
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | Y | 180 months |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | F | The item is an Aviation Critical Safety Item/Flight Safety Critical Aircraft Part ((ACSI/FSCAP). |
| Category | Code | Description |
|---|---|---|
| NMF Description | 194120 | WASHERS/GASKETS/PCKG DVCS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 596 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3110-00-067-9990
Air Force
Navy
Marines| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | Y | 180 months |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
| Combat Essentiality Code | 5 | Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency. |
| Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
| Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DM | U.S. Marine Corps |
| Service Organization | M | U.S. Marine Corps |
| Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | Y | 180 months |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | Y | 180 months |
| Purchasing | QTY UOM |
1 EA : Each |
