Product Details | HELICAL GEAR
3020-00-578-2241 A gear, cylindrical in form, with teeth on the outer surface at an angle to the axis of the gear. See also GEAR, ANTIBACKLASH, HELICAL
Part Alternates: B27774 , VBE40434, VBE404-34 , 352250015079 , 8528662, 11041031, 1104-103-1 , 12Z1311672, 12Z13116-72 , 13AT1 , 13AT104, 1564692 , 2535316, 2JC2865H04 , 2SB41, 2SB4-1 , 3020-00-578-2241, 00-578-2241, 3020005782241, 005782241
Mechanical Power Transmission Equipment | Gears, Pulleys, Sprockets, and Transmission Chain
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 30 | 14 DEC 1974 | 00-578-2241 | 05464 ( GEAR, HELICAL ) |
Drawings & Photos | NSN 3020-00-578-2241
Cross Reference | NSN 3020-00-578-2241
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2535316 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3020-00-578-2241
Related Products | NSN 3020-00-578-2241
Technical Data | NSN 3020-00-578-2241
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP E9310 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 6260 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | OXIDE OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | MIL-C-13924,CLASS 2 MIL SPEC SINGLE TREATMENT RESPONSE OVERALL |
| HARDNESS RATING | 36.0 ROCKWELL H MINIMUM AND 40.0 ROCKWELL H MAXIMUM BODY 58.0 ROCKWELL H MINIMUM AND 62.0 ROCKWELL H MAXIMUM TEETH |
| TEETH QUANTITY | 105 |
| TEETH TYPE | SINGLE HELIX |
| TOOTH FORM | STUB |
| TOOTH DIRECTION | LEFT |
| PRESSURE ANGLE | 20.0000 DEGREES |
| HELIX ANGLE | 23.0000 DEGREES |
| PRECISION CLASSIFICATION | QUALITY NUMBER 10 |
| BACKLASH DESIGNATION | GRADE C |
| STYLE DESIGNATOR | 4 PROTRUDING HUBS |
| PITCH DIAMETER | 3.5646 INCHES NOMINAL |
| NOMINAL OUTSIDE DIAMETER | 3.6094 INCHES |
| FACE NOMINAL WIDTH | 0.438 INCHES |
| NOMINAL DISTANCE BETWEEN BODY FACE AND PROTRUDING HUB END | 0.625 INCHES FIRST END 0.125 INCHES SECOND END |
| BORE STYLE | 1 PLAIN BOTH ENDS |
| BORE NOMINAL DIAMETER | 0.5001 INCHES BOTH ENDS |
| HUB STYLE DESIGNATOR | 4A 1 STEP FIRST END 1 PLAIN SECOND END |
| HUB NOMINAL DIAMETER | 1.000 INCHES SECOND END |
| END NOMINAL LENGTH | 0.6250 INCHES FIRST END |
| END NOMINAL DIAMETER | 0.7874 INCHES FIRST END |
| FIRST STEP NOMINAL LENGTH | 0.1250 INCHES FIRST END |
| FIRST STEP NOMINAL DIAMETER | 1.0000 INCHES FIRST END |
| BODY STYLE | 4B WEBBED, OFFSET, WITH LIGHTENING HOLES |
| ATTACHMENT METHOD | MOUNTING HOLE |
| MOUNTING HOLE TYPE AND QUANTITY | 1 PLAIN TRANSVERSELY THROUGH HUB, FIRST END |
| MOUNTING HOLE NOMINAL DIAMETER | 0.062 INCHES TRANSVERSELY THROUGH HUB, FIRST END |
Restrictions/Controls & Freight Information | NSN 3020-00-578-2241
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 197339 | WHEELS COG/GEAR/PINION I/S |
| Less than car load rating | ||
| Less than truck load rating | R | 65.0 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
