NSN 3020-00-342-5180 EZ108888, EZ10888-8, 325-016868
Product Details | SPROCKET WHEEL
3020-00-342-5180 A toothed wheel whose teeth or sprockets are designed to be engaged with the links of a pitch chain, track, or the like. It is usually used for transmitting power.
Part Alternates: EZ108888, EZ10888-8, 325-016868 , 46AY2256 , 83272, 8327-2, 1450141, 145014-1 , 17872 , 214, 247705, 24-7705 , 3020-00-342-5180, 00-342-5180, 3020003425180, 003425180, 325016868
Mechanical Power Transmission Equipment | Gears, Pulleys, Sprockets, and Transmission Chain
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 30 | 15 JAN 1974 | 00-342-5180 | 04456 ( SPROCKET WHEEL ) |
Drawings & Photos | NSN 3020-00-342-5180
Demand History | NSN 3020-00-342-5180
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 214 | 2019-04-108 | 40 | US |
| 214 | 2009-11-334 | 1 | United States |
| 3020-00-342-5180 | 2006-06-164 | 6 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3020-00-342-5180
Related Products | NSN 3020-00-342-5180
Technical Data | NSN 3020-00-342-5180
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | A2 PLAIN |
| OUTSIDE DIAMETER | 3.093 INCHES NOMINAL |
| OVERALL LENGTH | 0.860 INCHES NOMINAL |
| PITCH DIAMETER | 2.716 INCHES MINIMUM AND 2.721 INCHES MAXIMUM |
| FACE WIDTH | 0.122 INCHES MINIMUM AND 0.125 INCHES MAXIMUM |
| HUB END OUTSIDE DIAMETER AND LOCATION | 2.380 INCHES NOMINAL AA END |
| DISTANCE FROM OUTSIDE FLANGE/RIM TO HUB END AND LOCATION | 0.735 INCHES NOMINAL AA END |
| DESIGN FORM | SPOKED |
| LIGHTENING HOLE | NOT INCLUDED |
| TEETH ROW QUANTITY | 1 |
| TEETH QUANTITY PER ROW | 19 |
| MATERIAL | STEEL, CORROSION RESISTING |
| HARDNESS RATING TEST METHOD | ROCKWELL |
| TEETH HARDNESS RATING | 40.0 ROCKWELL C NOMINAL |
| METALLIC HARDNESS RATING AND LOCATION | 41.0 ROCKWELL C MINIMUM BODY AND 46.0 ROCKWELL C MAXIMUM BODY AND 41.0 ROCKWELL C MINIMUM HUB AND 46.0 ROCKWELL C MAXIMUM HUB |
| SURFACE TREATMENT | CADMIUM,QQ-P-416,TYPE 2,CLASS 3 |
| BORE BEARING | NOT INCLUDED |
| BORE TYPE | STRAIGHT |
| COUNTERBORE FEATURE | NOT INCLUDED |
| PROTRUDING HUB CHARACTERISTIC | PLAIN |
Restrictions/Controls & Freight Information | NSN 3020-00-342-5180
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 117020 | CHAIN AND SPROCKET DRIVES/WHEELS |
| Less than car load rating | ||
| Less than truck load rating | S | 60.0 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | ZB | Belgium ZC ZD |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3020-00-342-5180
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
