Product Details | ANGLE DRIVE UNIT

3010-01-236-1213 An assembly of gears, shaft and bearings within a housing, specifically designed to change the direction of rotary motion by an angle of more than zero degrees and less than one hundred eighty degrees. It may or may not have a torque differential from input to output. Excludes GEAR ASSEMBLY, SPEED DECREASER and GEAR ASSEMBLY, SPEED INCREASER.

Part Alternates: SP-334 1.133, SP3341133, RELSP334.1.133, RELSP3341133, 649CL, 649-CL, 74096231, 7409623-1, 3010-01-236-1213, 01-236-1213, 3010012361213, 012361213

Mechanical Power Transmission Equipment | Torque Converters and Speed Changers

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
30	12 JUL 1986	01-236-1213	62392 ( DRIVE UNIT, ANGLE )

Drawings & Photos | NSN 3010-01-236-1213

Part Number	Request Date	QTY	Origin
3010-01-236-1213	2019-05-148	1	United States
3010-01-236-1213	2012-12-363	0	DIBBS
3010-01-236-1213	2009-09-245	43	DIBBS
3010-01-236-1213	2009-06-166	558	DIBBS

Cross Reference | NSN 3010-01-236-1213

Part Number	Cage Code	Manufacturer
649-CL	57733	STEWART-WARNER CORPORATION
7409623-1	19207	U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM
7409623-1	65496	CLARK BROTHERS INSTRUMENT COMPANY
RELSP334.1.133	068D8	BRANDAMAR, INC. DBA BRANDAMAR
SP-334 1.133	0UKB6	WINDWARD ENTERPRISES, LLC DBA WINDWARD ENTERPRISES
