Product Details | EXHAUST MUFFLER

2990-00-135-4435 00020215600030Airframe Structural Components29900045Miscellaneous Engine Accessories, Nonaircraft

Part Alternates: 1043, 1216, 21457, 2264, 2501, 2781263, 41D, 5713, 958, PL54, 2990-00-135-4435, 00-135-4435, 2990001354435, 001354435

Engine Accessories | Miscellaneous Engine Accessories, Nonaircraft

Supply Group (FSG) NSN Assign. NIIN
29 06 JAN 1969 00-135-4435

Drawings & Photos | NSN 2990-00-135-4435


Demand History | NSN 2990-00-135-4435

Part Number Request Date QTY Origin
5713 2023-10-296 1 United States

Cross Reference | NSN 2990-00-135-4435

Part Number Cage Code Manufacturer
1043 81138 HAVILAND ARNOLD CO
1216 89799 ARVIN INDUSTRIES INC
21457 79260 WALKER MFG CO
2264 74080 HARVARD INDUSTRIES
2501 80266 AP PARTS CO INDUSTRIAL SALES DIV
2781263 12204 DAIMLER CHRYSLER
2781263 86403 CHRYSLER CORP SERVICE AND PARTS OPNS
41D 77432 INTERNATIONAL PARTS CORP DIV OF MIDAS-INTERNATIONAL CORP
5713 79260 WALKER MFG CO
958 0B0B1 MAHLE CLEVITE INC.
PL54 76110 MAREMONT CORP

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 2990-00-135-4435

Technical Data | NSN 2990-00-135-4435

Characteristic Specifications
MATERIAL STEEL
SURFACE TREATMENT ALUMINUM
DESIGN TYPE JACKETED
INSULATION MATERIAL ASBESTOS
MUFFLER DESIGN MULTIPASS
TUBE QUANTITY 3
BODY SHAPE OVAL
OVERALL LENGTH 25.312 INCHES NOMINAL
OVERALL WIDTH 9.750 INCHES NOMINAL
OVERALL HEIGHT 4.000 INCHES NOMINAL
OPERATING POSITION HORIZONTAL
INLET CONNECTION TYPE UNTHREADED
INLET LOCATION 0FFSET L0CATED 0N END 0F B0DY
INLET PROJECTION LENGTH 1.906 INCHES NOMINAL
INLET OUTSIDE DIAMETER ANY ACCEPTABLE
INLET INSIDE DIAMETER 1.875 INCHES NOMINAL
OUTLET CONNECTION TYPE UNTHREADED
OUTLET LOCATION CENTRALLY L0CATED 0N END 0F B0DY
OUTLET PROJECTION LENGTH 1.906 INCHES NOMINAL
OUTLET OUTSIDE DIAMETER ANY ACCEPTABLE
OUTLET INSIDE DIAMETER 1.750 INCHES NOMINAL

Restrictions/Controls & Freight Information | NSN 2990-00-135-4435

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information

Management | NSN 2990-00-135-4435

Category Code Description
Cognizance Codes9CNavy-owned stocks of defense construction material
Naval Inventory Control Point, Mechanicsburg
Source of SupplyS9CDefense Supply Center Columbus
Columbus, OH 43215
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesYTERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
