NSN 2930-01-491-1393 7008030, 700-8030, 700D8030
Product Details | ENGINE LUBRICATING OIL COOLER
2930-01-491-1393 A heat transfer device specifically designed to remove heat from lubricating oil to lower its temperature. Excludes radiators.20229300045Engine Cooling System Components, Nonaircraft29350055Engine System Cooling Components, Aircraft Prime Moving
Part Alternates: 7008030, 700-8030, 700D8030, 700-D-8030, 701-D-9619 REV B, 701D9619REVB, 2930-01-491-1393, 01-491-1393, 2930014911393, 014911393
Engine Accessories | Engine Cooling System Components, Nonaircraft
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 29 | 15 OCT 2001 | 01-491-1393 | 35373 ( COOLER, LUBRICATING OIL, ENGINE ) |
Drawings & Photos | NSN 2930-01-491-1393
Demand History | NSN 2930-01-491-1393
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 700-08030-000 | 2024-02-45 | 2 | DIBBS |
| 700-D-8030 | 2024-02-45 | 2 | DIBBS |
| 700-08030-000 | 2023-04-96 | 1 | DIBBS |
| 700-D-8030 | 2023-04-96 | 1 | DIBBS |
| 700-08030-000 | 2023-03-85 | 1 | DIBBS |
| 700-D-8030 | 2023-03-85 | 1 | DIBBS |
| 700-08030-000 | 2023-02-46 | 2 | DIBBS |
| 700-D-8030 | 2023-02-46 | 2 | DIBBS |
| 700-08030-000 | 2023-01-09 | 6 | DIBBS |
| 700-D-8030 | 2023-01-09 | 6 | DIBBS |
| 700-08030-000 | 2022-01-11 | 3 | DIBBS |
| 700-D-8030 | 2022-01-11 | 3 | DIBBS |
| 700-08030-000 | 2021-06-175 | 5 | DIBBS |
| 700-D-8030 | 2021-06-175 | 5 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2930-01-491-1393
Related Products | NSN 2930-01-491-1393
Technical Data | NSN 2930-01-491-1393
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY HOUSING STEEL SHELL COPPER ALLOY TUBES |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-C-15726 MIL SPEC SINGLE MATERIAL RESPONSE HOUSING ASTM A-108 FED SPEC SINGLE MATERIAL RESPONSE SHELL MIL-C-15726 MIL SPEC SINGLE MATERIAL RESPONSE TUBES |
| STYLE DESIGNATOR | A9 STRAIGHT FINNED TUBE CYLINDRICAL |
| DIAMETER | 14.000 INCHES NOMINAL |
| LENGTH | 58.000 INCHES MINIMUM AND 59.000 INCHES MAXIMUM |
| HEAT TRANSFER METHOD | INDIRECT |
| OIL FLOW RATE | 16.0 GALLONS PER MINUTE |
| SPECIAL FEATURES | ASSEMBLY CONSISTS OF ITEMS 1-14 ON DRAWING, MODEL NUMBER 2H-42C; DRAWING 701-C-9619 REV B IS THE INSTALLATION DRAWING. |
| III END ITEM IDENTIFICATION | WASP CLASS LHD |
| III PART NAME ASSIGNED BY CONTROLLING AGENCY | FDB LUBE OIL COOLER ASSEMBLY |
Restrictions/Controls & Freight Information | NSN 2930-01-491-1393
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 155150 | PETROLEUM: ADDITIVES, FUEL OIL, |
| Less than car load rating | ||
| Less than truck load rating | R | 65.0 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2930-01-491-1393
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
