NSN 2920-00-961-8262 IPD6L3412, L10202, VR154
Product Details | ENGINE GENERATOR REGULATOR
2920-00-961-8262 A regulator designed to automatically maintain the current and/or voltage output of an engine generator within specified limits, regardless of variation of load or input voltages. May include cutout relay. Does not include items in which regulation is accomplished by transformer action. See also REGULATOR, CURRENT and REGULATOR, VOLTAGE.20229200048Engine Electrical System Components, Nonaircraft29250058Engine Electrical System Components, Aircraft Prime Moving
Part Alternates: IPD6L3412, L10202, VR154, 6L3412, 9 000 590, 9000553, 9000590, 9MJ338, 051001, 05-1001, 1116393, 1116398, 1621888, 17542FX, 1769, 178340H1, 201616H1, 250349C91, 2920-00-961-8262, 00-961-8262, 2920009618262, 009618262
Engine Accessories | Engine Electrical System Components, Nonaircraft
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 29 | 25 MAY 1966 | 00-961-8262 | 17169 ( REGULATOR, ENGINE GENERATOR ) |
Drawings & Photos | NSN 2920-00-961-8262
Demand History | NSN 2920-00-961-8262
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1769 | 2024-10-295 | 400 | United States |
| 1769 | 2011-06-164 | 12 | US |
| 6L3412 | 2008-06-168 | 3 | US |
Cross Reference | NSN 2920-00-961-8262
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 05-1001 | 92860 | INTERNATIONAL PRODUCTS AND MANUFACTURING CO |
| 1116393 | 29510 | KOMATSU AMERICAN INTL CO |
| 1116398 | 077S2 | DELCO REMY AMERICA INC |
| 1116398 | 0SAT8 | KOMATSU AMERICA CORP. |
| 1116398 | 16764 | GENERAL MOTORS CORP DELCO REMY DIV |
| 1116398 | 29510 | KOMATSU AMERICAN INTL CO |
| 1116398 | 61928 | GENERAL MOTORS CORP AC-DELCO DIV |
| 1116398 | 7X677 | GENERAL MOTORS LLC DBA GENERAL MOTORS |
| 1621888 | 1X0J7 | VOLVO CONSTRUCTION EQUIPMENT NORTH AMERICA, LLC |
| 1621888 | 40152 | VME AMERICAS INC SUB OF VME GROUP N V |
| 17542FX | 45152 | OSHKOSH CORPORATION |
| 1769 | 16662 | LIFT PARTS MFG CO INC DIV OF ECHLIN MFG CO THE |
| 1769 | 66654 | TVH PARTS CO. |
| 178340H1 | 29510 | KOMATSU AMERICAN INTL CO |
| 201616H1 | 29510 | KOMATSU AMERICAN INTL CO |
| 250349C91 | 92679 | NAVISTAR INTL CORP MELROSE PARK ENGINE PLANT LOCATION |
| 6L3412 | 11083 | CATERPILLAR INC. DBA CATERPILLAR |
| 9 000 590 | 1LW55 | REMY, INC. |
| 9000553 | 077S2 | DELCO REMY AMERICA INC |
| 9000553 | 16764 | GENERAL MOTORS CORP DELCO REMY DIV |
| 9000590 | 077S2 | DELCO REMY AMERICA INC |
| 9000590 | 16764 | GENERAL MOTORS CORP DELCO REMY DIV |
| 9000590 | 24617 | GENERAL MOTORS CORP |
| 9000590 | 30379 | EUCLID INC |
| 9000590 | 61928 | GENERAL MOTORS CORP AC-DELCO DIV |
| 9MJ338 | 89619 | MACK TRUCKS, INC. DBA MACUNGIE OPERATIONS |
| IPD6L3412 | 55883 | INDUSTRIAL PARTS DEPOT INC |
| L10202 | 10988 | CNH INDUSTRIAL AMERICA LLC |
| VR154 | 19239 | ECHLIN INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2920-00-961-8262
Related Products | NSN 2920-00-961-8262
Technical Data | NSN 2920-00-961-8262
| Characteristic | Specifications |
|---|---|
| SYSTEM VOLTAGE RATING | 12.0 |
| SYSTEM GROUND POLARITY | NEGATIVE POSITIVE |
| VOLTAGE REGULATOR UNIT TYPE | TRANSISTOR |
| VOLTAGE REGULATOR UNIT QUANTITY | 1 |
| OUTPUT VOLTAGE RATING IN VOLTS | 13.7 MINIMUM 14.3 MAXIMUM |
| CIRCUIT CONTROL DEVICE TYPE | SOLID STATE CIRCUIT BOARD |
| CUT-IN VOLTAGE RATING | NOT RATED |
| CUTOUT VOLTAGE RATING | NOT RATED |
| CUTOUT CURRENT RATING IN AMPS | NOT RATED |
| REVERSE CURRENT OVERLOAD CIRCUIT BREAKER | NOT INCLUDED |
| FIELD RELAY UNIT | NOT INCLUDED |
| ENVIRONMENTAL PROTECTION | CORROSION RESISTANT WATERTIGHT |
| RADIO INTERFERENCE SHIELDING | NOT PROVIDED |
| TERMINAL TYPE | CONNECTOR, RECEPTACLE W/INTERNAL CONTACTS |
| TERMINAL QUANTITY | 3 |
| TERMINAL ENCASEMENT | ENCASED |
| CONDUIT CONNECTION QUANTITY | 1 |
| MOUNTING STYLE | 2 THREE HOLE TRIANGULAR |
| MOUNTING HOLE DIAMETER | 0.272 INCHES MINIMUM 0.282 INCHES MAXIMUM |
| DISTANCE BETWEEN HOLES ALONG WIDTH | 1.485 INCHES MINIMUM 1.515 INCHES MAXIMUM |
| CENTER TO CENTER DISTANCE BETWEEN HOLES ALONG WIDTH AND HOLE ALONG LENGTH | 5.045 INCHES MINIMUM 5.075 INCHES MAXIMUM |
| SHOCK MOUNT | NOT PROVIDED |
Restrictions/Controls & Freight Information | NSN 2920-00-961-8262
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062900 | RECTIFIERS NOI/BATTERY ELIMINATORS |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2920-00-961-8262
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
