NSN 2840-00-607-3469 201019, 5027T38P02, 00-607-3469
Product Details | AIRCRAFT GAS TURBINE ENGINE AIR SEAL
2840-00-607-3469 A rigid metallic item, generally circular. It may be formed of segmented arcs. It is designed to prevent leakage of air in an ENGINE, GAS TURBINE, AIRCRAFT. It may be of various cross-sectional shapes. It may have mounting facilities. It may act as a spacer but its primary function is as an air seal.
Part Alternates: 201019, 5027T38P02, 2840-00-607-3469, 00-607-3469, 2840006073469, 006073469
Engines, Turbines, and Components | Gas Turbines and Jet Engines, Aircraft, Prime Moving; and Components
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
28 | 30 JAN 1975 | 00-607-3469 | 50595 ( SEAL, AIR, AIRCRAFT GAS TURBINE ENGINE ) |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 2840-00-607-3469
Related Products | NSN 2840-00-607-3469
Technical Data | NSN 2840-00-607-3469
Characteristic | Specifications |
---|---|
CRITICALITY CODE JUSTIFICATION | AGAV |
III END ITEM IDENTIFICATION | ENGINE,ACFT,TURBOFAN,MODEL TF34GE100 |
MANUFACTURERS CODE | 99207 |
MFR SOURCE CONTROLLING REFERENCE | 5027T38P02 |
Restrictions/Controls & Freight Information | NSN 2840-00-607-3469
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
Controlled Inventory Item Code: | I | AIRCRAFT ENGINE EQUIPMENT AND PARTS |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 194120 | WASHERS/GASKETS/PCKG DVCS NOI SUB6 |
Less than car load rating | J | 100.2 |
Less than truck load rating | J | 100.2 |
Water commodity Code | 671 | unknown |
Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | ||
Air Special Handling | Z | No special handling required. |
Special Handling Code | Z | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2840-00-607-3469
Category | Code | Description |
---|---|---|
Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
Materiel Management Aggregation Code | OP | SX:TF-34 |
Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
Source of Supply | FHZ | Oklahoma City Air Logistics Center Tinker AFB, OK 73145-5989 |
Agency | DF | Department of the Air Force |
Service Organization | L | Lead Service - 22 (Repairable) |
Reparability | T | AF Recoverable Assembly Management System (AFRAMS) |
Acquisition Advice Codes | C | SERVICE/AGENCY-MANAGED (Service/Agency use only.) # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by individual Services supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with Service requisitioning procedures. |
Controlled Item Code | I | AIRCRAFT ENGINE EQUIPMENT AND PARTS |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Cognizance Codes | 7R | Aeronautical Depot Level Repairable Spares Naval Inventory Control Point, Philadelphia |
Special Material ID | SN | JET ENGINES(TF34-GE-2) |
Issue Repair, or Requisition | AR | Repairable item subject to centrally managed rework program at designated sites. Mandatory turn-in of item required except when initial issue or replacement of surveyed item is involved. |
Special Material Content | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
Source of Supply | NRP | NAVICP-ERP 700 Robbins Avenue Philadelphia, PA 19111-5098 |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Reparability | E | (1) IRAM Program Intensive Management Reparables (2) Material (expendable ordnance) Requiring Lot and Serial Number Control but which is Reported by Serial Number Only |
Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
Controlled Item Code | I | AIRCRAFT ENGINE EQUIPMENT AND PARTS |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
