NSN 2835-01-242-8063 GTCP85180, GTCP85-180, 38083417
Product Details | NONAIRCRAFT GAS TURBINE ENGINE
2835-01-242-8063 A continuous combustion type engine. Consists primarily of a COMPRESSOR, NONAIRCRAFT GAS TURBINE ENGINE; CHAMBER, COMBUSTION, NONAIRCRAFT GAS TURBINE ENGINE and a TURBINE ASSEMBLY, NONAIRCRAFT GAS TURBINE ENGINE. It may have a fan section. Air is compressed and heated by a combustible fuel and expanded through the turbine. It is designed to furnish a source of rotary shaft and/or pneumatic power. The pneumatic power is obtained by a bleedoff of the engine compressor. For a complete operating power unit, mounted on a base, see POWER UNIT, GAS TURBINE ENGINE.
Part Alternates: GTCP85180, GTCP85-180, 38083417, 380834-1-7, 38083418, 380834-1-8, 2835-01-242-8063, 01-242-8063, 2835012428063, 012428063
Engines, Turbines, and Components | Gas Turbines and Jet Engines; Non-Aircraft Prime Mover, Aircraft Non-Prime Mover, and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 28 | 17 OCT 1986 | 01-242-8063 | 50489 ( ENGINE, GAS TURBINE, NONAIRCRAFT ) |
Demand History | NSN 2835-01-242-8063
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2835-01-242-8063 | 2023-10-297 | 1 | US |
| 2835-01-242-8063 | 2016-12-344 | 1 | MANUAL |
| 38083417 | 2012-12-338 | 1 | TH |
| GTCP85180 | 2010-06-166 | 1 | US |
| GTCP85180 | 2009-05-151 | 1 | Singapore |
| 2835-01-242-8063 | 2006-07-194 | 3 | KE |
| 38083418 | 2006-04-114 | 1 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2835-01-242-8063
Technical Data | NSN 2835-01-242-8063
| Characteristic | Specifications |
|---|---|
| FUEL TYPE | JET FUEL |
| POWER OUTPUT FOR WHICH DESIGNED | PNEUMATIC |
| REFERENCE DATA AND LITERATURE | TO.2G-GTCP85-44 |
| SPECIAL FEATURES | TYPE/MODEL DESIGNATION:GTCP85-180 |
| III END ITEM IDENTIFICATION | AM32A-60A GENERATOR SET |
| MANUFACTURERS CODE | 99193 |
| DESIGN CONTROL REFERENCE | 380834-1-7 |
Restrictions/Controls & Freight Information | NSN 2835-01-242-8063
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | Y | Information is in the Hazardous Materials Information System (HMIS) |
| Demilitarization Code: | Q | Strategic List Item (SLI). Demilitarization not required. SLI are non-MLI(Munitions List Items) controlled by the U.S. Dept. of Commerce through the Export Administration Regulations (EAR) and indicated on the Commerce Control List (CCL). Each CCL entry is preceded by a four-digit Export Control Commerce Control List Item (CCLI) – MUT to the point of scrap required outside the United States. Inside the United States, MUT is required when the DEMIL integrity code (IC) is “3” and MUT is not required when the DEMIL IC is “6.” |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 120800 | ENGINES, INTERNAL COMBUSTION, NOI |
| Less than car load rating | M | 85 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | J | Materiel normally hazardous, rendered non-hazardous for shipment processing. (DD Form 1387-2 must certify to that effect.) |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | 1 | Aircraft engine, internal combustion engines and fuel control devices |
Management | NSN 2835-01-242-8063
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Materiel Management Aggregation Code | RP | SU:GAS TURBINE ENGINES (FSC RESIDUAL MMAC) |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | FGZ | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | T | AF Recoverable Assembly Management System (AFRAMS) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
