NSN 2835-01-055-4527 1057701, 105770-1, 1626891
Product Details | GAS TURBINE ENGINE COMPRESSOR ROTOR
2835-01-055-4527 A single or multistage assembly designed to deliver air at the proper pressure, direction and velocity. It consists of disks, blades, hubs, and the like. It is the moving part of a COMPRESSOR, NONAIRCRAFT GAS TURBINE ENGINE. It has facilities for attaching to a SHAFT, TURBINE, NONAIRCRAFT GAS TURBINE ENGINE.
Part Alternates: 1057701, 105770-1, 1626891, 162689-1, 2835-01-055-4527, 01-055-4527, 2835010554527, 010554527
Engines, Turbines, and Components | Gas Turbines and Jet Engines; Non-Aircraft Prime Mover, Aircraft Non-Prime Mover, and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 28 | 06 FEB 1978 | 01-055-4527 | 50588 ( ROTOR, COMPRESSOR, NONAIRCRAFT GAS TURBINE ENGINE ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2835-01-055-4527
Technical Data | NSN 2835-01-055-4527
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 2.515 INCHES MINIMUM AND 2.535 INCHES MAXIMUM |
| SPECIAL FEATURES | 8 FULL VANES 2.300 IN. MIN & 2.305 IN. MAX; BORE 0.785 IN. MIN & 0.795 IN. MAX DIA; STEPPED COUNTERBORE 0.766 IN. MIN & 0.772 IN. MAX DIA,1.398 IN. MIN & 1.402 IN. MAX DIA |
| END ITEM IDENTIFICATION | T62T-40 ENG |
| ENGINE SECTION LOCATION | COMPRESSOR |
| DIAMETER | 7.030 INCHES MINIMUM AND 7.040 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 2835-01-055-4527
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 118100 | COMPRESSORS, AIR, NOI, OR AIR ENDS |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Q | Extremely fragile items including delicate instruments. |
| Special Handling Code | Q | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2835-01-055-4527
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9G | Navy-owned stocks of defense general material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9G | Defense Supply Center Richmond Richmond, VA 23297 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
