NSN 2805-00-271-9554 MH5000100A5, MH5000-100A5, A1016
Product Details | ENGINE POPPET VALVE
2805-00-271-9554 A mushroom or tulip-shaped item having a circular head with a conical face and an extended stem used to regulate the flow of incoming fuel-air mixture or air into the combustion chamber or exhaust gases from the combustion chamber of a reciprocating internal combustion engine.20328050063Gasoline Reciprocating Engines, Except Aircraft; and Components28100068Gasoline Reciprocating Engines, Aircraft Prime Mover; and Components28150029Diesel Engines and Components
Part Alternates: MH5000100A5, MH5000-100A5, A1016, AE76N, AS2068, AS-2068, S2068, S-2068, S2635, S-2635, D1603, D-1603, D2069, D-2069, V-816, VI819 , WPP1585, 4428, 472078, V816, 1519, 2805-00-271-9554, 00-271-9554, 2805002719554, 002719554
Engines, Turbines, and Components | Gasoline Reciprocating Engines, Except Aircraft; and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 28 | 01 JAN 1963 | 00-271-9554 | 15884 ( VALVE, POPPET, ENGINE ) |
Drawings & Photos | NSN 2805-00-271-9554
Demand History | NSN 2805-00-271-9554
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4428 | 2019-09-248 | 1 | US |
| 1519 | 2013-06-172 | 3 | United States |
Cross Reference | NSN 2805-00-271-9554
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1519 | 54509 | NAPASCO INTERNATIONAL INC |
| 4428 | 81118 | EATON CORPORATION DBA FLUID POWER PLANT |
| 472078 | 00447 | WABCO CONSTRUCTION AND MINING EQUIPMENT GROUP INDIANAPOLIS PLANT |
| A1016 | 77576 | STERLING DIV FEDERAL MOGUL CORP |
| AE76N | 66289 | WISCONSIN MOTORS LLC |
| AS-2068 | 31033 | TRW INC TRW INTL TRADE GOVERNMENT SALES DEPT |
| D-1603 | 77220 | DANA CORP ENGINE PRODUCTS DIV |
| D-2069 | 95019 | DANA CORP SPICER TRANSMISSION DIV |
| MH5000-100A5 | 54764 | MANCRAFT INDUSTRIES INC |
| S-2068 | 31033 | TRW INC TRW INTL TRADE GOVERNMENT SALES DEPT |
| S-2635 | 31033 | TRW INC TRW INTL TRADE GOVERNMENT SALES DEPT |
| V-816 | 45225 | SERVICE SOLUTIONS U.S. LLC |
| V-816 | 53781 | SPX CORP |
| VI819 | 45225 | SERVICE SOLUTIONS U.S. LLC |
| VI819 | 53781 | SPX CORP |
| WPP1585 | 79172 | SIEMENS WATER TECHNOLOGIES CORP. DIV WALLACE & TIERNAN PRODUCTS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2805-00-271-9554
Technical Data | NSN 2805-00-271-9554
| Characteristic | Specifications |
|---|---|
| MATERIAL AND LOCATION | STEEL OVERALL |
| METALLIC HARDNESS RATING AND LOCATION | 50.0 SHORE SCLEROSCOPE MINIMUM TIP |
| HEAD STYLE | 8 RAISED FACE |
| HEAD HEIGHT | 0.1562 INCHES NOMINAL |
| OUTSIDE DIAMETER | 1.5570 INCHES MINIMUM AND 1.5670 INCHES MAXIMUM |
| NECK RADIUS | 0.2500 INCHES NOMINAL |
| SEAT ANGLE IN DEG | 45.0 |
| STEM STYLE | 5 GROOVED |
| GROOVE DIAMETER | 0.2670 INCHES MINIMUM AND 0.2730 INCHES MAXIMUM |
| CHAMFER LENGTH | 0.0156 INCHES MINIMUM AND 0.0312 INCHES MAXIMUM |
| GROOVE WIDTH | 0.0950 INCHES MINIMUM AND 0.1050 INCHES MAXIMUM |
| STEM LENGTH | 6.1718 INCHES NOMINAL |
| STEM DIAMETER | 0.3080 INCHES MINIMUM AND 0.3090 INCHES MAXIMUM |
| DISTANCE FROM GROOVE TO STEM END | 0.2400 INCHES MINIMUM AND 0.2500 INCHES MAXIMUM |
| CHAMFER ANGLE IN DEG | 45.0 |
| CARBON RELIEF GROOVE | NOT INCLUDED |
| III FSC APPLICATION DATA | GASOLINE ENGINE |
Restrictions/Controls & Freight Information | NSN 2805-00-271-9554
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2805-00-271-9554
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9C | Navy-owned stocks of defense construction material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9C | Defense Supply Center Columbus Columbus, OH 43215 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
