NSN 2530-01-474-5709 RBSK1513, 940001849A01, 9HR990

Product Details | BRAKE SHOE

2530-01-474-5709 A collection of items consisting of one or more LINING, FRICTION and brake shoe frame(s) with or without fastening devices such as rivets, bolts, nuts, bonding agents, and the like. For kits with additional items, see PARTS KIT, SHOE BRAKE. For assembled items, see BRAKE SHOE; BRAKE SHOE SET, INTERNALLY ACTUATED. See also LINING SET, FRICTION; BRAKE LINING KIT.20316300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components30400042Miscellaneous Power Transmission Equipment

Part Alternates: RBSK1513, 940001849A01, 9HR990, 2530-01-474-5709, 01-474-5709, 2530014745709, 014745709

Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components

Supply Group (FSG)	NSN Assign.	NIIN	Item Name Code (INC)
25	05 MAY 2000	01-474-5709	33853 ( PARTS KIT, BRAKE SHOE )
