Product Details | BRAKE SHOE SET

2530-01-420-1491 A group of replacement parts consisting of two or more BRAKE SHOE. It may include retaining springs, washers, shoe guide pins and the like. Excludes items furnished with backing plate, spider and/or hydraulic wheel cylinder(s), shoe segment sets for brake expander tubes, and BRAKE (as modified).20316300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components30400042Miscellaneous Power Transmission Equipment

Part Alternates: NW36295, 2530-01-420-1491, 01-420-1491, 2530014201491, 014201491

Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components

Supply Group (FSG) NSN Assign. NIIN
25 09 OCT 1995 01-420-1491

Demand History | NSN 2530-01-420-1491

Part Number Request Date QTY Origin
NW36295 2019-10-276 16 DIBBS
2530-01-420-1491 2012-06-170 1 US
NW36295 2012-05-140 4 US

Cross Reference | NSN 2530-01-420-1491

Part Number Cage Code Manufacturer
NW36295 44185 NMC/WOLLARD, INC.

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 2530-01-420-1491

Technical Data | NSN 2530-01-420-1491

Characteristic Specifications
END ITEM IDENTIFICATION SPECIAL AIRCRAFT AND ENGINE TOOL AND SUPPORT EQUIPMENT AND PARTS
MANUFACTURERS CODE 44185
DESIGN CONTROL REFERENCE NW36295

Restrictions/Controls & Freight Information | NSN 2530-01-420-1491

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 018400 AUTO BRAKES/SHOES R PADS ETC
Less than car load rating Q 70
Less than truck load rating Q 70.0
Water commodity Code 586 unknown
Originating Activity Code KE Naval ICP
Philadelphia, PA 19111
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 2530-01-420-1491

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Special Material Content9 Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesZINSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
