Product Details | MULTIPLE DISK BRAKE

2530-01-044-2125 A brake consisting essentially of the following: a. A brake anchor bracket, also called a carrier assembly, which is the basic unit of the brake. It is designed to be attached to the torque flange of the axle and is also the part upon which the other components of the brake are assembled. b. A floating hydraulically actuated annular piston, or an equivalent mechanical device, used for applying braking pressure. c. Metallic disks keyed to rotate with the wheel alternated with nonrotating disks keyed to the anchor bracket. See also BRAKE, SEGMENTED ROTOR.20316300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components30400042Miscellaneous Power Transmission Equipment

Part Alternates: H060398001, H060398-001, H603981, H60398-1, L60153, 2530-01-044-2125, 01-044-2125, 2530010442125, 010442125

Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components

Supply Group (FSG) NSN Assign. NIIN
25 09 JUL 1977 01-044-2125

Cross Reference | NSN 2530-01-044-2125

Part Number Cage Code Manufacturer
H060398-001 17904 DINGS CO DIV OF VENTUREDYNE LTD
H60398-1 17904 DINGS CO DIV OF VENTUREDYNE LTD
L60153 17904 DINGS CO DIV OF VENTUREDYNE LTD

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 2530-01-044-2125

Technical Data | NSN 2530-01-044-2125

Characteristic Specifications
OPERATION METHOD MECHANICAL
ROTATING DISK OUTSIDE DIAMETER 6.562 INCHES NOMINAL
ROTATING DISK THICKNESS 0.187 INCHES NOMINAL
STATIONARY DISK THICKNESS 0.187 INCHES NOMINAL
ROTATING DISK QUANTITY 2
INSTALLATION LOCATION RIGHT HAND FRONT
OVERALL DIAMETER 6.562 INCHES NOMINAL
OVERALL WIDTH 1.438 INCHES NOMINAL
MOUNTING METHOD ANCHOR PLATE FLANGE
MOUNTING HOLE QUANTITY 4
MOUNTING HOLE DIAMETER 0.406 INCHES NOMINAL
BOLT CIRCLE DIAMETER 5.875 INCHES NOMINAL

Restrictions/Controls & Freight Information | NSN 2530-01-044-2125

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 018400 AUTO BRAKES/SHOES R PADS ETC
Less than car load rating
Less than truck load rating Q 70.0
Water commodity Code 586 unknown
Originating Activity Code AX Defense Supply Center Columbus
Columbus, OH 43216-5000
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 2530-01-044-2125

Category Code Description
Cognizance Codes9BNavy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Source of SupplySMSDefense Logistics Agency
Enterprise Business Systems
AgencyDNDepartment of the Navy
Service OrganizationNU.S. Navy
Acquisition Advice CodesJNOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
