NSN 2530-00-753-9315 C12536E, 7539315, 1662M5
Product Details | HYDRAULIC BRAKE CYLINDER CUP
2530-00-753-9315 A circular-shaped item of molded synthetic or natural rubber designed specifically to seal fluid pressure and prevent leakage within the cylinders of a vehicular hydraulic brake system. It is a component of CYLINDER ASSEMBLY, HYDRAULIC BRAKE, MASTER or CYLINDER ASSEMBLY, HYDRAULIC BRAKE, WHEEL. Excludes CUP, COMPRESSION.20216300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components
Part Alternates: C12536E, 7539315, 1662M5, 2530-00-753-9315, 00-753-9315, 2530007539315, 007539315
Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 01 JAN 1962 | 00-753-9315 | 11359 ( CUP, HYDRAULIC BRAKE CYLINDER ) |
Demand History | NSN 2530-00-753-9315
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| C12536E | 2013-03-78 | 2 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2530-00-753-9315
Related Products | NSN 2530-00-753-9315
Technical Data | NSN 2530-00-753-9315
| Characteristic | Specifications |
|---|---|
| SIZE DESIGNATOR | 3/4 IN. |
| MATERIAL | RUBBER, NATURAL, SAE RN730 |
| MOUNTING METHOD | CENTER HOLE |
| TAPERED HOLE MAJOR DIAMETER | 0.135 INCHES MINIMUM AND 0.150 INCHES MAXIMUM |
| TAPERED HOLE MINOR DIAMETER | 0.110 INCHES MINIMUM AND 0.120 INCHES MAXIMUM |
| THRU-HOLE LENGTH | 0.156 INCHES MINIMUM AND 0.171 INCHES MAXIMUM |
| BASE INSIDE PROJECTION | INCLUDED |
| PROJECTION LENGTH | 0.0935 INCHES MINIMUM AND 0.1085 INCHES MAXIMUM |
| FEATHERED LIP FEATURE | NOT INCLUDED |
| CUP PROTECTOR | NOT INCLUDED |
| OUTER PERIPHERY BASE GROOVE | NOT INCLUDED |
| LARGEST OUTSIDE DIAMETER | 0.780 INCHES MINIMUM AND 0.790 INCHES MAXIMUM |
| BASE OUTSIDE DIAMETER | 0.715 INCHES MINIMUM AND 0.730 INCHES MAXIMUM |
| SEALING LIP LENGTH | 0.0625 INCHES MINIMUM AND 0.0775 INCHES MAXIMUM |
| OVERALL LENGTH | 0.156 INCHES MINIMUM AND 0.171 INCHES MAXIMUM |
| BASE THICKNESS | 0.062 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 2530-00-753-9315
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 011920 | AIRCRAFT BRAKES R PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 581 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2530-00-753-9315
Army
Air Force| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
