NSN 2530-00-590-2680 MS243261, MS24326-1, AA59494
Product Details | PNEUMATIC TIRE WHEEL
2530-00-590-2680 A wheel with an integral or removable rim designed to mount a pneumatic tire. Includes wheels without rims but designed to accommodate pneumatic tire rims. May include tire(s). Excludes WHEEL, LANDING GEAR.202253000002610000000
Part Alternates: MS243261, MS24326-1, AA59494, AA594940F0, AA59494-0F0, R101INNER, R101-INNER, R10-5.50, R10550, 31729, 41590, 4-1590, 6407, 02261-0064, 08OA02, 08-OA02, 1214D01, 1214D0-1, 2530-00-590-2680, 00-590-2680, 2530005902680, 022610064, 005902680
Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 01 JAN 1963 | 00-590-2680 | 17959 ( WHEEL, PNEUMATIC TIRE ) |
Drawings & Photos | NSN 2530-00-590-2680
Demand History | NSN 2530-00-590-2680
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2530-00-590-2680 | 2024-05-150 | 94 | DIBBS |
| 2530-00-590-2680 | 2024-04-95 | 94 | DIBBS |
| 2530-00-590-2680 | 2023-04-101 | 4 | United States |
| 2530-00-590-2680 | 2023-01-23 | 190 | DIBBS |
| 2530-00-590-2680 | 2023-01-08 | 190 | DIBBS |
| 2530-00-590-2680 | 2022-08-236 | 12 | United States |
| 2530-00-590-2680 | 2022-01-31 | 85 | DIBBS |
| 2530-00-590-2680 | 2022-01-20 | 275 | DIBBS |
| 2530-00-590-2680 | 2022-01-20 | 85 | DIBBS |
| 2530-00-590-2680 | 2022-01-12 | 275 | US |
| 2530-00-590-2680 | 2022-01-05 | 275 | DIBBS |
| 2530-00-590-2680 | 2021-09-252 | 274 | DIBBS |
| 2530-00-590-2680 | 2021-07-195 | 30 | United States |
| 2530-00-590-2680 | 2021-07-190 | 10 | US |
| 2530-00-590-2680 | 2020-06-174 | 225 | DIBBS |
| 2530-00-590-2680 | 2020-06-159 | 225 | DIBBS |
| 2530-00-590-2680 | 2019-10-301 | 259 | DIBBS |
| 2530-00-590-2680 | 2019-08-219 | 71 | DIBBS |
| 2530-00-590-2680 | 2019-08-218 | 2 | US |
| 2530-00-590-2680 | 2019-05-136 | 276 | DIBBS |
| 2530-00-590-2680 | 2019-05-123 | 120 | US |
| 2530-00-590-2680 | 2019-01-03 | 132 | DIBBS |
| 2530-00-590-2680 | 2018-11-329 | 129 | DIBBS |
| 2530-00-590-2680 | 2018-08-242 | 156 | DIBBS |
| 2530-00-590-2680 | 2018-07-205 | 93 | DIBBS |
| 2530-00-590-2680 | 2018-07-193 | 233 | DIBBS |
| AA594940F0 | 2018-01-12 | 4 | United States |
| 2530-00-590-2680 | 2015-09-246 | 240 | DIBBS |
| 2530-00-590-2680 | 2015-07-186 | 96 | DIBBS |
| 2530-00-590-2680 | 2015-05-137 | 219 | DIBBS |
| 2530-00-590-2680 | 2015-03-78 | 600 | DIBBS |
| 2530-00-590-2680 | 2015-03-67 | 600 | DIBBS |
| 2530-00-590-2680 | 2014-06-175 | 86 | DIBBS |
| 6407 | 2013-11-326 | 3 | US |
| 2530-00-590-2680 | 2012-06-181 | 90 | DIBBS |
| 2530-00-590-2680 | 2012-02-54 | 125 | DIBBS |
| 2530-00-590-2680 | 2012-02-39 | 86 | DIBBS |
| 2530-00-590-2680 | 2011-11-318 | 78 | DIBBS |
| 2530-00-590-2680 | 2011-08-213 | 99 | DIBBS |
| 2530-00-590-2680 | 2010-04-97 | 326 | DIBBS |
| 2530-00-590-2680 | 2010-03-64 | 194 | DIBBS |
| AA594940F0 | 2010-01-14 | 88 | US |
| 2530-00-590-2680 | 2009-11-316 | 79 | DIBBS |
| AA594940F0 | 2009-10-293 | 4 | US |
| 2530-00-590-2680 | 2009-09-244 | 92 | DIBBS |
| MS243261 | 2009-02-36 | 1 | US |
| 2530-00-590-2680 | 2008-04-94 | 582 | DIBBS |
| AA59494 | 2008-03-71 | 1 | us |
| 2530-00-590-2680 | 2007-08-219 | 161 | DIBBS |
| 2530-00-590-2680 | 2007-04-93 | 77 | DIBBS |
| 2530-00-590-2680 | 2007-01-24 | 180 | DIBBS |
| 2530-00-590-2680 | 2006-07-185 | 50 | DIBBS |
Cross Reference | NSN 2530-00-590-2680
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 02261-0064 | 93568 | HARSCO CORP BMY-COMBAT SYSTEMS DIV |
| 08-OA02 | 62589 | TRAILER COMPONENT MANUFACTURING INC. |
| 1214D0-1 | 83269 | DUAL DRIVE INC |
| 31729 | 0W357 | PDI GROUND SUPPORT SYSTEMS, INC. |
| 4-1590 | 0W357 | PDI GROUND SUPPORT SYSTEMS, INC. |
| 6407 | 52793 | SAGINAW PRODUCTS CORPORATION DBA CIGNYS |
| AA59494 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| AA59494-0F0 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| MS24326-1 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| R10-5.50 | 08999 | SAVOY MFG INC |
| R101-INNER | 93547 | FALLS STAMPING AND WELDING CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2530-00-590-2680
Related Products | NSN 2530-00-590-2680
Technical Data | NSN 2530-00-590-2680
| Characteristic | Specifications |
|---|---|
| TIRE RIM NOMINAL DIAMETER | 9.968 INCHES |
| TIRE | NOT INCLUDED |
| DESIGN FORM | DISK |
| DISK TYPE | DOUBLE |
| LIGHTENING HOLE | NOT INCLUDED |
| DESIGN TYPE | DIVIDED WHEEL |
| GROOVE DEPTH | 0.855 INCHES MINIMUM AND 0.925 INCHES MAXIMUM |
| OVERALL WIDTH | 6.580 INCHES NOMINAL |
| METAL THICKNESS | 0.1793 INCHES MINIMUM AND 0.1875 INCHES MAXIMUM |
| MOUNTING TYPE FOR WHICH DESIGNED | SINGLE TIRE |
| HUB CHARACTERISTIC | DEMOUNTABLE |
| HUB | NOT INCLUDED |
| PILOT HOLE DIAMETER | 4.000 INCHES NOMINAL |
| MOUNTING HOLE QUANTITY | 5 |
| MOUNTING HOLE DIAMETER | 0.531 INCHES NOMINAL |
| MOUNTING BOLT CIRCLE DIAMETER | 5.500 INCHES NOMINAL |
| III END ITEM IDENTIFICATION | GRUMMAN A-10 AIRCRAFT |
| MANUFACTURERS CODE | 58536 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AA59494 |
| MANUFACTURERS CODE | 58536 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AA59494-0F0 |
Restrictions/Controls & Freight Information | NSN 2530-00-590-2680
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 197592 | WHEELS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 885 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2530-00-590-2680
Army
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
