NSN 2520-01-273-0604 127740X, 15Z484, 01-273-0604
Product Details | CLUTCH DISK
2520-01-273-0604 A solid circular disk of wire-woven lining material or ceramic and metal substance and the like, molded to one or both sides and fastened directly or indirectly to the center spline or hub, which receives and transmits motion or power by engagement with the pressure plate assembly and the flywheel or the like. Includes dry or wet type disk, and may include damper springs. This item is designed to be used on tanks, automobiles, construction equipment, and the like in conjunction with a CLUTCH ASSEMBLY, FRICTION.
Part Alternates: 127740X, 15Z484, 2520-01-273-0604, 01-273-0604, 2520012730604, 012730604
Vehicular Equipment Components | Vehicular Power Transmission Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 19 FEB 1988 | 01-273-0604 | 52060 ( DISK, CLUTCH, VEHICULAR ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2520-01-273-0604
Technical Data | NSN 2520-01-273-0604
| Characteristic | Specifications |
|---|---|
| DESIGN TYPE | DRY |
| FLEXIBILITY | RIGID |
| DISK TYPE | INTERNAL TEETH |
| SPLINE TYPE | STRAIGHT |
| SPLINE QUANTITY | 10 |
| FEATURES PROVIDED | FRICTION MATERIAL FACING |
| SPECIAL FEATURES | INTEGRAL HUB INCLUDED |
| III END ITEM IDENTIFICATION | CRANE,HARNISCHFEGER,OMEGA 65 |
| (NON-CORE DATA) DESIGN FORM | SOLID |
Restrictions/Controls & Freight Information | NSN 2520-01-273-0604
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 126840 | POWER TRANS BELT CLAMPS,GUIDES ETC |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 586 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2520-01-273-0604
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
