NSN 2320-01-500-9249 GS30F1046D, 01-500-9249, 015009249
Product Details | VAN TRUCK
2320-01-500-9249 A truck with a cab not integral with the inclosed body, designed to protect cargo and equipment from the elements, pilferage, and/or to provide working quarters for personnel. It may be insulated, have windows, lighting, and/or ventilation. Excludes TRUCK, PANEL.20223200034Trucks and Truck Tractors, Wheeled23550047Combat, Assault, and Tactical Vehicles, Wheeled
Part Alternates: GS30F1046D, 2320-01-500-9249, 01-500-9249, 2320015009249, 015009249
Ground Effect Vehicles, Motor Vehicles, Trailers, and Cycles | Trucks and Truck Tractors, Wheeled
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
23 | 16 SEP 2002 | 01-500-9249 | 11348 ( TRUCK, VAN ) |
Cross Reference | NSN 2320-01-500-9249
Part Number | Cage Code | Manufacturer |
---|---|---|
GS30F1046D | 98752 | WARNER ROBINS AIR LOGISTICS CENTER |
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 2320-01-500-9249
Related Products | NSN 2320-01-500-9249
Technical Data | NSN 2320-01-500-9249
Characteristic | Specifications |
---|---|
VEHICLE MAXIMUM GROSS WEIGHT | 35000.00 POUNDS |
WHEEL QUANTITY | 4 |
DRIVE WHEEL QUANTITY | 2 |
DRIVE AXLE LOCATION | REAR |
AXLE DRIVE TYPE | ANY ACCEPTABLE |
REAR WHEEL MOUNTING TYPE | DUAL |
NOMINAL WHEELBASE | 262.00 INCHES |
PRIME MOVER TYPE | ANY ACCEPTABLE |
TRANSMISSION TYPE | AUTOMATIC |
FORWARD SPEED RANGE QUANTITY | 5 |
FORWARD SPEED QUANTITY PER RANGE | 1 |
SEATING CAPACITY | 5 |
BATTERY QUANTITY | 3 |
BATTERY VOLTAGE RATING IN VOLTS | 12.0 |
BRAKE ACTUATION METHOD | AIR |
BODY MATERIAL | ALUMINUM |
CARGO AREA NOMINAL LENGTH | 252.00 INCHES |
CARGO AREA NOMINAL WIDTH | 100.00 INCHES |
CARGO AREA NOMINAL HEIGHT | 132.00 INCHES |
SPECIAL FEATURES | EOD VEHICLE; ROOF ACCESS; ROBOT COMPARTMENT; BOMB SUIT STORAGE CLOSET; RUNNING LIGHTS |
Restrictions/Controls & Freight Information | NSN 2320-01-500-9249
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | C | Munitions List Item or Commerce Control List Item. Demilitarization required. Remove and/or demilitarize installed key point(s) as prescribed in the Defense Demilitarization Manual, or lethal parts, components and accessories. |
Controlled Inventory Item Code: | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
Category | Code | Description |
---|---|---|
NMF Description | 190190 | VEHICLE MTR:AUTO FRT NOI TRACTORS |
Less than car load rating | ||
Less than truck load rating | F | 150.0 |
Water commodity Code | 891 | unknown |
Originating Activity Code | TK | HQ AFMC/GLSC 401 SCM/GUMB Wright-Patterson AFB, OH 45433-5000 |
Air Dimension Code | Z | Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions. |
Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
Air Special Handling | D | Hazardous material (not required hand to hand receipt) including all regulated items other than special weapons and their components. |
Special Handling Code | R | unknonwn |
HAZMAT | ||
Type of Cargo | R | Flammable liquids, UN class 3 (flammable liquids label) |
Management | NSN 2320-01-500-9249
Category | Code | Description |
---|---|---|
Fund Code | AF | HQ USAF regulated. |
Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
Budget Code | V | 8257X3080:Vehicular Equip (REMS) Vehicle Items and centrally funded, procured, and managed replenishment spares (ERRC XD-1, XD-2) |
Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
Agency | DF | Department of the Air Force |
Service Organization | L | Lead Service - 22 (Repairable) |
Reparability | U | AF Equipment Management System (AFEMS) |
Acquisition Advice Codes | W | RESTRICTED REQUISITIONING-SPECIAL INSTRUCTIONS APPLY (NON-STOCKED ITEMS) Indicates stock number has been assigned to a generic item for use in bid invitations, allowance lists, etc., against which no stocks are ever recorded. Requisitions will be submitted only in accordance with IMM/Service requisitioning procedures. (This code will be used, when applicable, in conjunction with Phrase Code S (Stock as NSN(s)). It is considered applicable for use when a procurement source(s) becomes available. The Phrase Code S and the applicable stock as? NSN(s) will then be applied for use in stock, store and issue actions.) |
Controlled Item Code | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
Shelf Life Code | 0 | Nondeteriorative |
