Product Details | VAN TRUCK

2320-00-935-0750 A truck with a cab not integral with the inclosed body, designed to protect cargo and equipment from the elements, pilferage, and/or to provide working quarters for personnel. It may be insulated, have windows, lighting, and/or ventilation. Excludes TRUCK, PANEL.20223200034Trucks and Truck Tractors, Wheeled23550047Combat, Assault, and Tactical Vehicles, Wheeled

Part Alternates: FEDSTD794, FED-STD-794, MILT45339, D500, 2320-00-935-0750, 00-935-0750, 2320009350750, 009350750

Ground Effect Vehicles, Motor Vehicles, Trailers, and Cycles | Trucks and Truck Tractors, Wheeled

Supply Group (FSG) NSN Assign. NIIN
23 11 APR 1967 00-935-0750

Drawings & Photos | NSN 2320-00-935-0750


Cross Reference | NSN 2320-00-935-0750

Part Number Cage Code Manufacturer
D500 18113 CHRYSLER CORP HAMTRAMCK ASSEMBLY
FED-STD-794 06542 FEDERAL STANDARDS PROMULGATED BY GENERAL SERVICES
MILT45339 81349 MILITARY SPECIFICATIONS PROMULGATED BY MILITARY

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 2320-00-935-0750

Technical Data | NSN 2320-00-935-0750

Characteristic Specifications
RATED LOAD CAPACITY 2.50 TONS
VEHICLE MAXIMUM GROSS WEIGHT 19000.00 POUNDS
WHEEL QUANTITY 6
DRIVE WHEEL QUANTITY 4
DRIVE AXLE LOCATION REAR
AXLE DRIVE TYPE CONVENTIONAL
AXLE SPEED QUANTITY 1
REAR WHEEL MOUNTING TYPE DUAL
NOMINAL WHEELBASE 175.00 INCHES
FRONT WHEEL TREAD NOMINAL WIDTH 66.52 INCHES
REAR WHEEL TREAD NOMINAL WIDTH 69.50 INCHES
PRIME MOVER TYPE GASOLINE ENGINE
CYLINDER QUANTITY 8
ENGINE BRAKE HORSEPOWER 202.0
ENGINE HORSEPOWER RATING SPEED IN RPM 3900.0
TRANSMISSION TYPE MANUAL
FORWARD SPEED QUANTITY 4
REVERSE SPEED QUANTITY 1
SEATING CAPACITY 3
CAB TYPE CONVENTIONAL
CAB DOOR QUANTITY 2
CAB ROOF TYPE CLOSED
BATTERY QUANTITY 3
BATTERY VOLTAGE RATING IN VOLTS 12.0
BRAKE ACTUATION METHOD AIR AND HYDRAULIC
FEATURES PROVIDED ELECTRICAL OUTLET AND INSULATED AND TRAILER BRAKE CONNECTION
INTERIOR ELECTRICAL OUTLET VOLTAGE 12 115
TRAILER BRAKE CONNECTION TYPE ANY ACCEPTABLE
BODY MATERIAL ALUMINUM AND WOOD OR STEEL AND WOOD
CARGO AREA NOMINAL LENGTH 162.00 INCHES
CARGO AREA NOMINAL WIDTH 84.00 INCHES
CARGO AREA NOMINAL HEIGHT 76.00 INCHES
CARGO DOOR LOCATION REAR FACING
WINDOW QUANTITY 11
NONDEFINITIVE SPEC/STD DATA 7 TYPE AND B CLASS
REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS AS DIFFERENTIATED BY ITEM NAME AND MODEL YEAR 1967 REQUIREMENTS
III BODY MANUFACTURER CODE AND MODEL NUMBER 02342 SHOP VAN
III ENGINE/MOTOR MANUFACTURER CODE AND MODEL NUMBER 18113 318-3
III CHASSIS MANUFACTURER CODE AND MODEL NUMBER 18113 D500
MANUFACTURERS CODE 06542
NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE FED-STD-794
MANUFACTURERS CODE 18113
DESIGN CONTROL REFERENCE D500

Restrictions/Controls & Freight Information | NSN 2320-00-935-0750

Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodeYInformation is in the Hazardous Materials Information System (HMIS)
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 190190 VEHICLE MTR:AUTO FRT NOI TRACTORS
Less than car load rating M 85
Less than truck load rating F 150.0
Water commodity Code 891 unknown
Originating Activity Code BE
Air Dimension Code Z Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling D Hazardous material (not required hand to hand receipt) including all regulated items other than special weapons and their components.
Special Handling Code R unknonwn
HAZMAT
Type of Cargo B Mixed hazardous materials - consolidated only as authorized by Coast Guard regulations, Title 49, CFR, use with T-2 or T-3 documents only

Management | NSN 2320-00-935-0750

Category Code Description
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Budget CodeV 8257X3080:Vehicular Equip (REMS) Vehicle Items and centrally funded, procured, and managed replenishment spares (ERRC XD-1, XD-2)
Source of SupplyFLZWarner Robins Air Logistics Center
Robins AFB, GA 31098-5609
AgencyDFDepartment of the Air Force
Service OrganizationLLead Service - 22 (Repairable)
ReparabilityUAF Equipment Management System (AFEMS)
Acquisition Advice CodesVTERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
