NSN 1650-00-767-5905 706013, 00-767-5905, 007675905
Product Details | MECHANICAL DRIVE HOUSING
1650-00-767-5905 An item fabricated from a single, internally cored casting, or composed of two or more separate castings, and designed to position and protect bearings, shafts, gears, and/or other components required for a mechanical drive. Includes items having access hole(s) to facilitate machining and assembling of components. It may include the access hole cover plate(s).20511900057Specialized Test and Handling Equipment, Nuclear Ordnance16500058Aircraft Hydraulic, Vacuum, and De-icing System Components2520000030400042Miscellaneous Power Transmission Equipment39500037Winches, Hoists, Cranes, and Derricks
Part Alternates: 706013, 1650-00-767-5905, 00-767-5905, 1650007675905, 007675905
Aircraft Components and Accessories | Aircraft Hydraulic, Vacuum, and De-icing System Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 16 | 08 MAR 1968 | 00-767-5905 | 60627 ( HOUSING, MECHANICAL DRIVE ) |
Cross Reference | NSN 1650-00-767-5905
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 706013 | 99167 | HAMILTON SUNDSTRAND CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 1650-00-767-5905
Technical Data | NSN 1650-00-767-5905
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | C/O INSERT,SCREW THD SELF-LOCKING:16 EA P/N MS212109C1-20,9 EA P/N MS21209C4-20,2 EA P/N MS21209F6-15,1 EA P/N MS21209C08-15,4 EA P/N MS21209C1-15,12 EA MS21209C04-15,16 EA P/N MS21209C6-20,3 EA P/N MS21209C6-15,1 EA P/N MS21209C4-15;1 INPUT HOUSING P/N 706013-1;8 SHOULDERED STUDS P/N 698704-1;1 INSERT O-RING P/N 1021-5;2 SLEEVE BUSHINGS P/N 695401;2 STRAIGHT HEADLESS PINS P/N 1802-12-12H;2 SLEEVE BUSHINGS P/N 691797;3 BEARING LINERS P/N'S 695803,695804 AND 699105;2 INSERTS SCREW THD P/N'S 690775-10 AND -12;2 O-RINGS P/N'S MS17413-120 AND 123;AS REQ'D-DRY FILM LUBRICANT P/N MS3452-02 AND SHOULDERED STUD P/N 698704-2 |
| MANUFACTURERS CODE | 99167 |
| DESIGN CONTROL REFERENCE | 706013 |
Restrictions/Controls & Freight Information | NSN 1650-00-767-5905
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | SX | Oklahoma City Air Logistics Center Tinker AFB, OK 73145-3043 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
