Product Details | VORTEX GENERATOR

1560-01-600-4852 A small blade type airfoil mounted perpendicular to an aerodynamic surface (wing, empennage). Its primary purpose is to prevent the separation of boundary layer air to eliminate shock waves which cause buffeting of control surfaces.

Part Alternates: 65C1716721, 65C17167-21, 1560-01-600-4852, 01-600-4852, 1560016004852, 016004852

Aircraft and Airframe Structural Components | Airframe Structural Components

Supply Group (FSG) NSN Assign. NIIN
15 02 DEC 2011 01-600-4852

Demand History | NSN 1560-01-600-4852

Part Number Request Date QTY Origin
65C17167-21 2020-12-351 0
1560-01-600-4852 2020-12-350 0 NECO
65C17167-21 2019-04-120 1
1560-01-600-4852 2019-04-117 1 NECO
65C17167-21 2016-02-40 1
1560-01-600-4852 2016-02-37 1 NECO
65C17167-21 2015-05-135 2
1560-01-600-4852 2015-05-133 2 NECO
65C17167-21 2015-01-24 2
1560-01-600-4852 2015-01-22 2 NECO
65C17167-21 2014-05-122 1
1560-01-600-4852 2014-05-121 1 NECO

Cross Reference | NSN 1560-01-600-4852

Part Number Cage Code Manufacturer
65C17167-21 81205 THE BOEING COMPANY DBA BOEING

Request a Quote

What Our Customers Say

Compare

NSNs for Compare ( up to 4 ): Add 1560-01-600-4852

Technical Data | NSN 1560-01-600-4852

Characteristic Specifications
OVERALL LENGTH 16.0 INCHES NOMINAL
MATERIAL THICKNESS 7.0 INCHES NOMINAL
SPECIAL FEATURES WEIGHT 10.0 LBS; AIRFLOW CONTROL FOR APU INLET
OVERALL WIDTH 8.0 INCHES NOMINAL
MATERIAL STEEL CORROSION RESISTING
PART NAME ASSIGNED BY CONTROLLING AGENCY APU INLET FLAP AND VORTEX GENERATOR ASSEMBLY

Restrictions/Controls & Freight Information | NSN 1560-01-600-4852

Category Code Description
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:BMunitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.)
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
No Freight Information
