NSN 1377-01-290-1751 CCU-91/B, CCU91B, DL6106213
Product Details | IMPULSE CARTRIDGE
1377-01-290-1751 An item consisting of a quantity of propellant and a means of activation inclosed in a container. It may contain an integral cutting punch. It is designed to be inserted into or attached to one or more devices to provide the energy required to operate a device not requiring a time delay in their operating sequence. It is used in devices, such as initiators, thrusters, cutters, and the like. For cartridges with a time delay see CARTRIDGE, DELAY.20611450054Explosive and Pyrotechnic Components, Nuclear Ordnance13200022Ammunition, over 125mm13360048Guided Missile Warheads and Explosive Components13400048Rockets, Rocket Ammunition and Rocket Components13770056Cartridge and Propellant Actuated Devices and Components13850059Surface Use Explosive Ordnance Disposal Tools and Equipment
Part Alternates: CCU-91/B, CCU91B, DL6106213, 1377MT12, 1377-MT12, 6106213, 1377-01-290-1751, 01-290-1751, 1377012901751, 012901751
Ammunition and Explosives | Cartridge and Propellant Actuated Devices and Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 13 | 07 DEC 1988 | 01-290-1751 | 27118 ( CARTRIDGE, IMPULSE ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 1377-01-290-1751
Technical Data | NSN 1377-01-290-1751
| Characteristic | Specifications |
|---|---|
| BODY DIAMETER | 1.155 INCHES NOMINAL |
| OVERALL LENGTH | 2.275 INCHES NOMINAL |
| UNIT PACKAGE QUANTITY | 4 |
| UNIT PACKAGE TYPE | CAN, METAL |
| DOD AMMUNITION CODE | 1377-MT12 |
| CARTRIDGE MODEL NUMBER | CCU-91/B |
| SPECIAL FEATURES | USED FOR EMERGENCY CARGO EJECTION ON B-1 AIRCRAFT |
| III UNPACKAGED UNIT WEIGHT | 0.077 POUNDS |
| III NET EXPLOSIVE WEIGHT | 0.044 STORAGE POUNDS AND 0.044 TRANSPORTATION POUNDS |
| III HAZARDOUS MATERIAL CLASSIFICATION CODE | 1.4 DEPARTMENT OF DEFENSE HAZARD CLASS DIVISION |
| III DOT PROPER SHIPPING NAME | CARTRIDGES, POWER DEVICE |
| III DOT IDENTIFICATION NUMBER | UN0276 |
| III DOT REGISTRATION CODE | EX1987090244 |
| MANUFACTURERS CODE | 53711 |
| DESIGN CONTROL REFERENCE | 6106213 |
Restrictions/Controls & Freight Information | NSN 1377-01-290-1751
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | G | Munitions List Item or Commerce Control List Item. Demilitarization required. Ammunition, explosives, and dangerous articles (AEDA). Demilitarization, and if required, declassification and/or removal of sensitive markings or information, will be accomplished. This code will be used for all AEDA items, including those which also require declassification and/or removal of sensitive markings or information. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | N | The item does not have a critical feature such as tolerance, fit restrictions or application. Nuclear hardness properties have not been determined (not valid for input). |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
