NSN 1015-00-523-0374 5230374, 5J470, M065
Product Details | ARTILLERY CLEANING BRUSH
1015-00-523-0374 A brush specially designed for cleaning the bore, breech, or other component parts of an artillery weapon. It may be a brush unit only or it may be provided with a handle or staff and/or have facilities for attachment thereto.20610100026Guns, over 30mm up to 75mm10150024Guns, 75mm through 125mm10200030Guns, over 125mm through 150mm10250030Guns, over 150mm through 200mm10300030Guns, over 200mm through 300mm10350016Guns, over 300mm
Part Alternates: 5230374, 5J470, M065, 1015-00-523-0374, 00-523-0374, 1015005230374, 005230374
Weapons | Guns, 75mm through 125mm
Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
---|---|---|---|
10 | 01 JAN 1963 | 00-523-0374 | 22300 ( BRUSH, CLEANING, ARTILLERY ) |
Demand History | NSN 1015-00-523-0374
Part Number | Request Date | QTY | Origin |
---|---|---|---|
1015-00-523-0374 | 2018-09-270 | 10 | DIBBS |
1015-00-523-0374 | 2018-08-221 | 10 | DIBBS |
1015-00-523-0374 | 2014-01-12 | 8 | DIBBS |
1015-00-523-0374 | 2012-02-55 | 20 | DIBBS |
Cross Reference | NSN 1015-00-523-0374
Request a Quote
What Our Customers Say
Compare
NSNs for Compare ( up to 4 ): Add 1015-00-523-0374
Related Products | NSN 1015-00-523-0374
Technical Data | NSN 1015-00-523-0374
Characteristic | Specifications |
---|---|
STYLE DESIGNATOR | M7 FLAT, WOODEN HANDLE |
OVERALL LENGTH | 8.500 INCHES NOMINAL |
BRUSH PART WIDTH | 0.025 INCHES NOMINAL |
BRUSH LENGTH | 3.500 INCHES NOMINAL |
BRUSH PART MATERIAL | WIRE |
HANDLING FACILITY TYPE | HANDLE |
BRUSH MODEL NUMBER | M23 |
BRUSH SIZE DESIGNATION | 105MM |
MANUFACTURERS CODE | 80572 |
DESIGN CONTROL REFERENCE | 5J470 |
Restrictions/Controls & Freight Information | NSN 1015-00-523-0374
Category | Code | Description |
---|---|---|
Shelf-Life Code: | 0 | Nondeteriorative |
Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
Controlled Inventory Item Code: | U | UNCLASSIFIED |
Precious Metals Indicator Code: | A | Item does not contain precious metal |
Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
Category | Code | Description |
---|---|---|
NMF Description | 033100 | BROOM BRUSHES O/T FLOOR |
Less than car load rating | ||
Less than truck load rating | W | Rating Variable |
Water commodity Code | 748 | unknown |
Originating Activity Code | XX | |
Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
Air Commodity | 2 | Arms/Weapons (all types including Inert Component Parts). When a 2 is indicated in the first position, then the special handling code must be determined from table 85 , part 1. |
Air Special Handling | Z | No special handling required. |
Special Handling Code | 9 | unknonwn |
HAZMAT | ||
Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 1015-00-523-0374
Category | Code | Description |
---|---|---|
Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
Combat Essentiality Code | 5 | Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency. |
Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
Echelon Identification Code | K | Reserved |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DM | U.S. Marine Corps |
Service Organization | M | U.S. Marine Corps |
Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
Category | Code | Description |
---|---|---|
Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
Agency | DN | Department of the Navy |
Service Organization | N | U.S. Navy |
Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
Controlled Item Code | U | UNCLASSIFIED |
Shelf Life Code | 0 | Nondeteriorative |
Purchasing | QTY UOM |
1 EA : Each |
